The ViewSonic CDE8630 is an 86-inch 4K UHD digital signage display designed for continuous 24/7 operation in corporate and educational environments across the GCC and Africa. Featuring a quad-core processor, 450-nit brightness, and USB-C connectivity, it supports landscape or portrait orientation. Smart-Boards supplies this series with logistics tailored to regional needs.
This 86-inch TFT LCD panel delivers a native 3840 x 2160 resolution with 1.07 billion colors and a 1200:1 contrast ratio. The ADS-type screen ensures 178-degree viewing angles horizontally and vertically, while the anti-glare surface with 3H hardness protects the display in high-traffic areas. The slim 14.7mm bezel allows for tight tiling configurations, and the unit supports both landscape and portrait mounting orientations for flexible deployment in lobbies, classrooms, or retail spaces.
Built for sustainability, the CDE8630 operates continuously with a typical power consumption of 172W and standby power below 0.5W. It includes a quad-core ARM Cortex A55 processor, 4GB RAM, and 32GB storage to run embedded applications efficiently. Connectivity options include USB-C with 65W PD charging, USB 3.0, HDMI, RS-232, and an RJ45 port. The display accommodates OPS modules and WiFi slots, enabling robust content management and remote updates via myViewBoard Manager for multi-site deployments.
Key features
- 4K UHD Clarity - The 86-inch panel provides a native 3840 x 2160 resolution with 1.07 billion colors and 1200:1 contrast for sharp, detailed visual content.
- USB-C Connectivity - A single USB-C cable supports DP 1.2, USB 2.0, 100M Ethernet, and 65W power delivery for simplified device connections.
- Continuous Operation - Designed for 24/7 use, the display features a typical brightness of 450 nits and low standby consumption under 0.5W.
- Flexible Orientation - Supports landscape and portrait modes with slim 14.7mm bezels, ideal for vertical digital signage or wide presentation layouts.
- Expandable Slots - Includes one OPS slot and one WiFi slot for adding computing modules or wireless connectivity to enhance system functionality.
Ideal for: Suitable for corporate lobbies, university campuses, ministries, and retail spaces across the GCC and Africa requiring reliable, high-brightness digital signage.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- CDE8630
- Key features
- All-in-one solution, Embedded Signage Platform, Integrated RJ45 and USB Wi-Fi, ViewBoard Cast content sharing, myViewBoard Display app, Remote management, AV control system interoperability, Tiling matrix, Landscape/Portrait mode
- Orientation
- Landscape & Portrait
Display
- Backlight
- Direct LED
- Brightness
- 450 cd/m²
- Colour depth
- 10-bit (1.07 billion colours)
- Resolution
- 4K UHD
- Screen size
- 86"
- Surface protection
- Anti-glare, 3H hardness, 25% haze
- Viewing angle
- 178° (H) / 178° (V)
- Aspect ratio
- 16:9
- Contrast ratio
- 1,200:1 (typ.), 5,000:1 (DCR)
- Panel technology
- ADS
- Response time
- 8 ms
System
- Processor
- Amlogic T982
- Operating system
- Android 11
- RAM
- 4 GB
- Storage
- 32 GB
- Operating hours
- 24/7
Connectivity
- Bluetooth
- Built-in
- Ethernet (RJ45)
- RJ45 × 1
- HDMI input
- HDMI In × 3
- HDMI output
- HDMI Out × 1
- Serial port
- RS-232 × 1
- USB-C
- USB-C × 1
- USB ports
- USB 3.0 × 1, USB 2.0 × 1
- Wi-Fi
- Built-in
Camera & audio
- Audio out
- SPDIF out × 1
- Speaker output
- 2 × 10 W
Physical & warranty
- In the box
- Wi-Fi adapter, Wall mount, Remote control with batteries, Quick start guide, Power cable, HDMI cable, USB-C cable, Screws, RS232 cable
- Operating humidity
- 10% to 90% RH
- Operating temperature
- 0°C to 40°C
- Power consumption
- 172 W (typical)
- Standby power
- ≤ 0.5 W
- Dimensions
- 1930.8 x 1101.8 x 81.6 mm
- Weight
- 43.2 kg
- Shipping dimensions
- 2110 x 1227 x 225 mm
- VESA mount
- 800 x 600 mm, M8 x 25 mm
- Warranty
- 3 years (parts, labor and backlight)
- Bezel size
- 14.7 mm
- Input voltage
- 100–240 V AC
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
What are the physical dimensions of the ViewSonic CDE8630?
The unit measures 1930.8 x 1101.8 x 81.6mm (76.02 x 43.38 x 3.21 inches) with a net weight of 43.15kg. Packaging dimensions are 2110 x 1227 x 225mm, and the gross weight is 60.75kg.
Can this display be installed outside the UAE?
Smart-Boards provides on-site installation within the UAE only. For other GCC and African countries, the display ships ready for local setup, with remote guidance available if needed to assist local technicians.
Which countries does Smart-Boards deliver to?
We ship to all GCC nations including the UAE, KSA, Qatar, Kuwait, Oman, and Bahrain, as well as various African countries. Delivery times vary by location and order size and are confirmed in the quotation.
Does the CDE8630 support 24/7 operation?
Yes, the CDE30 Series is purpose-engineered for continuous 24/7 display in corporate and campus environments. It maintains typical brightness of 450 nits and operates within 0 to 40°C temperatures.
What operating system is built into the display?
The display uses a quad-core ARM Cortex A55 processor with 4GB RAM and 32GB storage. It supports embedded content management via myViewBoard Display and vCast for screen casting without external computers.
How does the USB-C port function?
The single USB-C port supports DP 1.2 video output, USB 2.0 data transfer, 100M Ethernet, and 65W power delivery. It also supports Smart USB features for direct device interaction and content access.
Is remote management available for multi-site deployments?
Yes, the display is compatible with myViewBoard Manager, allowing administrators to update software, broadcast content, and manage settings remotely. This ensures consistent operation across multiple sites in the GCC and Africa.
