The Trend TD-55ID20U-Di7 is a 55-inch interactive flat panel featuring a 3840×2160 UHD display and 20-point infrared touch capability. It operates on a dual Android and Windows system with an Intel Core i7 processor, supplied by Smart-Boards across the GCC and African regions.
This 55-inch interactive display integrates a dual operating system environment, allowing users to switch between Android 6.0 and Windows 7/8/10 environments. The unit is powered by an Intel Core i7 processor alongside a Cortex A53 Android chip, supported by up to 16GB RAM and a 120GB SSD for Windows. The 4mm tempered glass front provides durability, while the 450cd/m² brightness and 2000:1 contrast ratio ensure visibility in well-lit conference rooms and classrooms. The chassis includes built-in 2x5W speakers and a temperature-controlled cooling fan for sustained 24-hour operation.
Smart-Boards supplies this Trend interactive panel to educational institutions, government ministries, and corporate offices throughout the UAE, KSA, Qatar, Kuwait, Oman, and Bahrain. The device supports versatile installation via wall mounts, fixed floor stands, or movable bases. We provide live or virtual demonstrations before purchase and offer quote-only pricing with education and bulk tender options. Delivery times are confirmed per quotation, and on-site installation is available within the UAE, while other regions receive ready-to-setup units with remote guidance.
Key features
- Dual OS Platform - Runs Android 6.0 and Windows 7/8/10 simultaneously using an Intel Core i7 processor and Cortex A53 chip.
- UHD Visuals - Features a 55-inch S-IPS panel with 3840×2160 resolution, 450cd/m² brightness, and 178° viewing angles.
- Multi-Touch Input - Supports 20 simultaneous touch points via an infrared frame with over 90% accuracy in a 2mm touch area.
- Flexible Connectivity - Includes HDMI, VGA, USB, RJ45, and AV ports for direct connection to laptops, media players, and network infrastructure.
- Durability & Cooling - Protected by 4mm tempered glass and equipped with a temperature-controlled fan for stable 24-hour daily operation.
Ideal for: Classrooms, boardrooms, and government halls across the GCC and Africa requiring a robust 55-inch display for collaborative work and presentations.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- SD card slot
- SD Card × 1
- Key features
- 20-point infrared touch, Dual OS Android and Windows, Intel Core i7, 4 mm tempered glass, 24/7 operation, Remote control, Wall or floor installation
Display
- Backlight
- D-LED
- Brightness
- 450 cd/m²
- Colour depth
- 8-bit (16.7 million colours)
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 55"
- Surface protection
- 4mm tempered glass
- Viewing angle
- 178° (H) / 178° (V)
- Contrast ratio
- 2,000:1
- Panel technology
- IPS
- Response time
- 8 ms
Touch
- Touch points
- 20 Points Multi Touch
- Touch response time
- 8 ms
- Touch technology
- Infrared
System
- Processor
- Cortex A53 × 4 1.5 GHz (Android), A77-I7/3520M/3540M (Windows)
- Graphics
- Arm Mali-T720 MP2 (Android), Intel HD 3000 (Windows)
- Operating system
- Android 6
- RAM
- 1.5 GB (Android) / 4 GB (Windows)
- Storage
- 32 GB
- Memory type
- DDR3
- Operating hours
- 24/7
Connectivity
- Ethernet (RJ45)
- RJ45 × 2
- HDMI input
- HDMI In × 3
- Serial port
- DB9 × 1
- Touch USB ports
- Touch USB × 1
- USB ports
- USB 3.0 × 2, USB 2.0 × 1
- VGA input
- VGA × 1
- Wi-Fi
- Built-in WiFi
Camera & audio
- Audio in
- AV In × 1
- Audio out
- AV Out × 1
- Speaker output
- 2 × 6Ω/5W
- Speaker type
- Built-in Speakers
Physical & warranty
- Operating humidity
- 20%~80% RH
- Operating temperature
- 0℃~50℃
- Power consumption
- 385 W
- Dimensions
- 1960.6 × 1161.8 × 96.8 mm
- Weight
- 67 kg
- Warranty
- 1 years
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Does this model include a built-in PC?
Yes. The unit integrates a dual operating system with an Intel Core i7 processor, 4GB RAM, and a 120GB SSD for Windows, plus Android 6.0 capabilities.
Can it be installed outside the UAE?
On-site installation is provided within the UAE only. For other GCC and African countries, units are delivered ready for local setup with remote guidance available.
Which countries receive delivery?
We ship to the UAE, KSA, Qatar, Kuwait, Oman, Bahrain, and selected African nations via established logistics partners at competitive costs.
Is installation included in the price?
Pricing is by quotation only. Installation is included for UAE deliveries; other regions receive delivery-ready units with optional remote support.
What is the warranty coverage?
The product comes with a 1-year manufacturer warranty. Smart-Boards also provides after-sales support for all supplied units.
Does it support dual displays?
Yes, the Windows OS supports horizontal and portrait display modes for multi-screen setups or extended desktop configurations.
What accessories are included?
The package includes a remote control, a base or bracket for installation, and WiFi connectivity components for wireless operation.
Delivery across the GCC & Africa
We ship to the UAE, Saudi Arabia, Qatar, Kuwait, Bahrain, Oman and across Africa at the lowest possible cost through established logistics partners. Lead times and freight are stated clearly in your quotation.
On-site installation in the UAE
Professional installation, mounting and configuration are available within the UAE. Outside the UAE the product arrives ready for local installation, with remote setup guidance from our team.
- Export-grade packing and transit insurance
- Procurement-ready documents for tenders and projects
- Wall mount or mobile stand fitting (UAE)
- Manufacturer warranty, optional annual maintenance contract
Ready to equip your space?
Get a tailored quote for the GCC & Africa — pricing, availability and project support in one reply.
