The Trend TD-55ID20U-Di3 is a 55-inch interactive flat panel designed for collaborative environments across the GCC and Africa. It features a 3840×2160 UHD display, 20-point infrared touch, and dual Android/Windows operating systems. Smart-Boards supplies this unit with installation support in the UAE and logistics to regional markets.
This 55-inch display integrates an Intel i3 processor with 4GB of Windows memory and an Android 6.0 system for versatile computing. The screen delivers 450cd/m² brightness and a 2000:1 contrast ratio through S-IPS technology. It supports 20 simultaneous touch points with high accuracy across the 16:9 area. The unit includes built-in 2×5W speakers and temperature-controlled cooling for stable operation.
Smart-Boards offers this interactive display to schools, ministries, and corporate offices in the GCC and Africa. We provide quote-only pricing with options for bulk, education, and government tenders. Installation is available on-site within the UAE, while other countries receive ready-to-setup units with remote guidance. The package includes a remote, bracket, and WiFi adapter for immediate deployment.
Key features
- Dual Operating Systems - Runs on Android 6.0 and Windows 7/8/10 with an Intel i3 processor and 120GB SSD for flexible computing.
- UHD Interactive Screen - Features a 55-inch 3840×2160 display with 450cd/m² brightness and 20-point infrared touch capability.
- Robust Connectivity - Includes three HDMI inputs, VGA, USB touch ports, and dual RJ45 sockets for reliable network integration.
- Durable Construction - Protected by 4mm tempered glass that is level 7 earthquake resistant and resistant to daily wear.
- Flexible Mounting - Supports on-wall, movable, or fixed floor-standing installation types to suit various room layouts.
- Included Accessories - Comes with a remote control, base bracket, and WiFi module for immediate setup and wireless connectivity.
Ideal for classrooms, conference rooms, and government offices across the GCC and Africa requiring reliable, high-contrast interactive displays.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- SD card slot
- SD card × 1
- Key features
- 20-point infrared touch, Dual OS Android and Windows, Intel Core i3, 4 mm tempered glass, 24/7 operation, Remote control, Wall or floor installation
Display
- Backlight
- D-LED
- Brightness
- 450 cd/m²
- Colour depth
- 8-bit (16.7 million colours)
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 55"
- Surface protection
- 4mm tempered glass
- Viewing angle
- 178° (H) / 178° (V)
- Contrast ratio
- 2,000:1
- Panel technology
- IPS
- Response time
- 8 ms
Touch
- Touch points
- 20 Points Multi Touch
- Touch response time
- 8 ms
- Touch technology
- Infrared
System
- Processor
- ARM Cortex-A53 1.5 GHz (Android), Intel Core i3 (Windows)
- Graphics
- Arm Mali-T720 MP2 (Android), Intel HD 3000 (Windows)
- Operating system
- Android 6
- RAM
- 1.5 GB (Android) / 4 GB (Windows)
- Storage
- 32 GB
- Memory type
- DDR3
- Operating hours
- 24/7
Connectivity
- Ethernet (RJ45)
- RJ45 × 2
- HDMI input
- HDMI In × 3
- Serial port
- Serial × 1 (DB9)
- Touch USB ports
- USB (touch screen) × 1
- USB ports
- USB 3.0 × 2, USB 2.0 × 1
- VGA input
- VGA × 1 (Rear)
- Wi-Fi
- Built-in WiFi
Camera & audio
- Audio out
- Earphone × 1
- Speaker output
- 2 × 6Ω/5W
- Speaker type
- Built-in Speakers
Physical & warranty
- Operating humidity
- 20%~80% RH
- Operating temperature
- 0℃~50℃
- Power consumption
- 385 W
- Dimensions
- 1960.6 × 1161.8 × 96.8 mm
- Weight
- 67 kg
- Warranty
- 1 years
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Is this product available for purchase in the GCC and Africa?
Yes, Smart-Boards supplies the Trend TD-55ID20U-Di3 to customers in the UAE, KSA, Qatar, Kuwait, Oman, Bahrain, and African countries. We ship through established logistics partners at competitive rates.
Does the unit include an operating system?
Yes, it features a dual operating system with Android 6.0 and Windows 7/8/10. The Windows configuration includes an Intel i3 processor and a 120GB SSD for immediate use.
What is the touch technology and accuracy?
It uses an infrared touch frame that supports 20 simultaneous touch points. The accuracy covers more than 90% of the touch area with a 2mm precision level.
Is installation provided outside the UAE?
On-site installation is only available within the UAE. For other countries, units are delivered ready for local setup with remote guidance from our technical team.
What is the warranty coverage?
The product comes with a 1-year manufacturer warranty. Smart-Boards provides after-sales support to assist with any technical issues or maintenance needs.
Can I connect external devices to this panel?
Yes, it has three HDMI inputs, one VGA port, USB touch interfaces, and dual RJ45 sockets. It also includes AV in/out and headphone audio output for versatile connectivity.
What accessories are included in the box?
The package includes a remote control, a base/bracket for mounting, and a WiFi adapter. A user manual, warranty card, and certificate of conformity are also provided.
Delivery across the GCC & Africa
We ship to the UAE, Saudi Arabia, Qatar, Kuwait, Bahrain, Oman and across Africa at the lowest possible cost through established logistics partners. Lead times and freight are stated clearly in your quotation.
On-site installation in the UAE
Professional installation, mounting and configuration are available within the UAE. Outside the UAE the product arrives ready for local installation, with remote setup guidance from our team.
- Export-grade packing and transit insurance
- Procurement-ready documents for tenders and projects
- Wall mount or mobile stand fitting (UAE)
- Manufacturer warranty, optional annual maintenance contract
