The SMART Board 6086S-V3 interactive flat panel (model SBID-6286S-V3-B) is an 86-inch 4K UHD display designed for collaborative environments. Featuring HyPr Touch technology with up to 40 touch points and built-in iQ software on Android 11, it supports modern hybrid workflows. Smart-Boards supplies this unit to schools, universities, and enterprises across the GCC and Africa.
This 86-inch interactive flat panel delivers 4K UHD clarity with a brightness of ≥ 350 nits and a 178° viewing angle, ensuring visibility in large conference rooms and lecture halls. The HyPr Touch system supports up to 40 simultaneous touch points with ±1 mm accuracy, enabling multiple users to interact with content simultaneously. Integrated dual 20 W speakers and a four-microphone array facilitate clear audio for video conferencing and presentations without external equipment.
Connectivity is robust, featuring three HDMI 2.1 ports, two USB-C inputs supporting 4K @ 60 Hz, and an OPS slot for 60 W devices. The display runs on Android 11 with 6 GB RAM and 32 GB storage, including SMART Notebook software for enhanced collaboration. Connectivity options include dual-band Wi-Fi, Bluetooth 5.0, and dual RJ45 Ethernet ports. The unit weighs 86 kg and includes a wall mount, pens, and remote control for immediate deployment.
Key features
- 4K UHD Display - The 86-inch screen provides 3840 x 2160 resolution with LED backlighting and ≥ 350 nits brightness for clear visuals.
- 40-Point Touch - HyPr Touch with InGlass technology allows up to 40 simultaneous touch points with ±1 mm accuracy for multi-user collaboration.
- Built-in iQ System - Android 11 operating system with 6 GB RAM and 32 GB storage includes SMART Notebook software and OTA update capabilities.
- Comprehensive Ports - Includes three HDMI 2.1, two USB-C (4K @ 60 Hz), three USB 3.0, and an OPS slot for flexible device integration.
- Audio & Connectivity - Features dual 20 W speakers, a linear four-microphone array, dual-band Wi-Fi, Bluetooth 5.0, and dual RJ45 Ethernet ports.
Ideal for classrooms, boardrooms, and training centers requiring high-interaction displays, suitable for buyers across the GCC and Africa seeking reliable, multi-site AV solutions.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- SBID-6286S-V3-B
- Product type
- Interactive Flat Panel
- Key features
- 4K UHD display, up to 40 touch points, Android 11 iQ, SMART Notebook included, two 20 W speakers, NFC sign-in, Wi-Fi 802.11 a/b/g/n/ac, OTA updates
Display
- Colour
- Black
- Backlight
- LED
- Brightness
- 350 cd/m²
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 86"
- Viewing angle
- 178°
- Aspect ratio
- 16:9
- Response time
- ≤ 8 ms
Touch
- Touch accuracy
- ±1 mm
- Touch points
- Up to 40 touch points (OS dependent)
- Touch technology
- HyPr Touch with InGlass
System
- OPS slot
- 1 (back), for 60 W devices
- Operating system
- Android 11
- RAM
- 6 GB
- Storage
- 32 GB
- Storage conditions
- -20 to 60 °C
Connectivity
- Bluetooth
- Bluetooth 5.0 (dual mode)
- Ethernet (RJ45)
- RJ45 × 2 (1000baseT)
- USB-C
- USB-C × 2 (1 front, 1 back): 4K @ 60 Hz, DisplayPort 1.2, USB 2.0 (UFP) for touch and digital audio
- USB ports
- USB 3.0 Type-A × 3 (1 front, 2 back), USB 2.0 Type-A × 1 (back), USB 2.0 Type-B × 1 (front), USB 3.0 Type-B × 3 (back)
- Wi-Fi
- 802.11 a/b/g/n/ac, 2 × 2 MIMO, 2.4 and 5 GHz
- Ports
- HDMI 2.1 with HDCP 1.4 and 2.3 × 3 (1 front, 2 back), HDMI 2.1 × 1 (back), VGA × 1 (back), RS-232 × 1 (back), 3.5 mm stereo × 1 (back), S/PDIF × 1 (back)
- Connectivity options
- Wi-Fi, Bluetooth 5.0, RJ45 × 2, integrated NFC
Camera & audio
- Audio
- 2 × 20 W integrated speakers
- Microphone
- Integrated linear four-microphone array
Physical & warranty
- In the box
- Pens (2), erasers (2), USB cable, remote control, WM-SBID-200 wall mount, SMART ID cards (2), dual-band 2.4 and 5 GHz antennae (3)
- Operating humidity
- 5% to 80% RH, non-condensing
- Operating temperature
- 5 to 35 °C
- Power consumption
- 161 W (typical)
- Standby power
- 0.4 W
- Dimensions
- 2005 x 1221 x 124 mm
- Weight
- 86 kg
- VESA mount
- 600 x 400 mm (M8)
- Input voltage
- 100–240 V AC, 50/60 Hz
- Certifications
- CE, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, WEEE, ENERGY STAR
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
What is the resolution of the SMART Board 6086S-V3?
The display has a 4K UHD resolution of 3840 x 2160 pixels, providing sharp image quality for detailed presentations and interactive content.
Does this model support multi-touch?
Yes, the HyPr Touch technology supports up to 40 simultaneous touch points, depending on the operating system, allowing multiple users to interact with the screen at once.
Which countries can receive this product?
Smart-Boards ships to GCC countries including UAE, KSA, Qatar, Kuwait, Oman, and Bahrain, as well as African nations, via established logistics partners.
Is installation included outside the UAE?
On-site installation is available within the UAE only. For other countries, the unit is delivered ready for local setup, with remote guidance provided if needed.
What is the weight of the 86-inch display?
The unit weighs 86 kg, requiring appropriate mounting hardware such as the included WM-SBID-200 wall mount or a compatible VESA 600 x 400 mm mount.
Does it have built-in wireless capabilities?
Yes, it includes dual-band 2.4 and 5 GHz Wi-Fi (802.11 a/b/g/n/ac) and Bluetooth 5.0 for wireless connectivity and peripheral pairing.
What is included in the box?
The package contains the display, WM-SBID-200 wall mount, two pens, two erasers, a remote control, USB cable, two SMART ID cards, and three dual-band antennae.
