The Samsung VM55B-U (LH55VMBUBGBXUE) is a 55-inch commercial video wall display designed for continuous operation. It features an ultra-narrow 1.25mm/2.25mm bezel and 500 nit IPS panel. Smart-Boards supplies this unit across the GCC and Africa for corporate and educational deployments.
This 55-inch display utilises an IPS panel delivering 1,920 x 1,080 resolution at 500 nits typical brightness. The ultra-narrow bezel measures 1.25mm on the right and bottom, and 2.25mm on the top and left, ensuring minimal visual interruption in multi-screen configurations. With a 178-degree viewing angle and 45,000:1 dynamic contrast, it maintains clarity in various lighting conditions. The glossy frame and 24/7 operation support make it suitable for high-traffic commercial environments.
Connectivity includes two HDMI 2.0 inputs, one DisplayPort 1.2, and DVI in, alongside RS232 and RJ45 for control. The set weighs 21.2 kg and supports VESA 600 x 400 mounting without a stand. It operates within 0°C to 40°C temperature ranges. Smart-Boards ships these units to GCC and African countries via established logistics partners, offering live demonstrations and on-site installation within the UAE only, with remote guidance for other regions.
Key features
- Ultra-Narrow Bezel - Features 1.25mm (R/B) and 2.25mm (U/L) bezel widths for seamless video wall integration.
- Commercial Durability - Designed for 24/7 continuous operation with IP5X dust resistance and 500 nit brightness.
- Signal Connectivity - Provides two HDMI 2.0, one DP 1.2, and DVI inputs with RS232 and RJ45 control options.
- VESA Mounting - Supports VESA 600 x 400mm mounting patterns; no stand included for flexible wall or rigging installation.
- Wide Viewing Angle - IPS panel technology ensures consistent colour and image quality at 178-degree horizontal and vertical angles.
Ideal for corporate lobbies, control rooms, and educational institutions requiring reliable multi-screen displays across the GCC and Africa.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- VM55B-U
- Key features
- Razor Narrow Bezel, ACM Support (Advanced Color Management), Temperature Sensor, Video Wall Daisy Chain (10×10), DP 1.2 Digital Daisy Chain (Supporting UHD Resolution, HDCP support), Clock Battery (168 hrs Clock Keeping), Auto Source Switching & Reco
- Orientation
- Portrait / Landscape
Display
- Brightness
- 500 cd/m²
- Resolution
- Full HD
- Screen size
- 55"
- Viewing angle
- 178° (H) / 178° (V)
- Contrast ratio
- 1,200:1
- Panel technology
- IPS
- Response time
- 8 ms
System
- Operating hours
- 24/7
Connectivity
- DisplayPort
- DisplayPort 1.2
- Ethernet (RJ45)
- RJ45 × 1
- HDMI input
- HDMI In × 2
- Serial port
- RS-232 × 1
- USB ports
- USB × 1
Camera & audio
- Audio in
- 3.5 mm audio in
- Audio out
- 3.5 mm audio out
Physical & warranty
- In the box
- Quick Setup Guide, Warranty Card, DP cable, Stereo to DB9 cable, Power Cord, Remote Controller, Batteries, External IR
- Operating humidity
- 10% to 80% RH
- Operating temperature
- 0°C to 40°C
- Power consumption
- 220 W
- Standby power
- < 0.5 W
- Dimensions
- 1213.5 x 684.3 x 73.1 mm
- Weight
- 21.2 kg
- Shipping dimensions
- 1398 x 844 x 257 mm
- VESA mount
- 600 x 400 mm
- Shipping weight
- 28.8 kg
- Bezel size
- 2.25 mm (T/L), 1.25 mm (R/B)
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
What are the bezel dimensions of the Samsung VM55B-U?
The bezel width is 1.25mm on the right and bottom edges, and 2.25mm on the top and left edges. This asymmetry helps optimise the visual balance in video wall layouts.
Which countries can this product be delivered to?
Smart-Boards delivers to all GCC countries (UAE, KSA, Qatar, Kuwait, Oman, Bahrain) and various African nations through established logistics partners. Delivery times depend on the specific country and order size.
Is on-site installation available outside the UAE?
No. On-site installation is provided only within the UAE. For other countries, the product is delivered ready for local setup, with remote guidance available if needed to assist with configuration.
Does the Samsung VM55B-U include a stand?
No, the set does not include a stand. It supports VESA 600 x 400mm mounting, allowing for flexible wall or ceiling rigging solutions suitable for video wall configurations.
What is the typical brightness level of this display?
The typical brightness is 500 nits. This ensures adequate visibility in well-lit commercial environments, supported by a 1,200:1 static contrast ratio and 178-degree viewing angles.
Can this unit operate continuously?
Yes, the Samsung VM55B-U is designed for 24/7 operation. It supports continuous use in commercial settings and operates within a temperature range of 0°C to 40°C.
What warranty and support does Smart-Boards provide?
Smart-Boards is an authorised reseller offering the manufacturer warranty plus Smart-Boards after-sales support. Pricing is by quotation, and we provide live or virtual demonstrations before purchase.
