The Panasonic TH-86SQ1H is an 86-inch 4K digital signage display designed for high-brightness environments across the GCC and Africa. Featuring 1200 cd/m² luminance and 24/7 operational capability, it suits airports, malls, and corporate lobbies. Smart-Boards supplies this model from Dubai with regional logistics and quotation-based pricing.
This 86-inch (2174.2 mm) panel delivers 4K resolution (3840 x 2160) with a typical brightness of 1200 cd/m², ensuring clear visibility in well-lit atriums and conference areas. The anti-glare low reflection surface (Haze 3%) reduces ambient light interference, while the 1200:1 contrast ratio maintains image depth. Built for continuous operation, it supports 24-hour daily use in temperatures from 0°C to 40°C, making it reliable for diverse regional climates.
Installation flexibility is supported by VESA 600 x 400 mm wall-mounting and Portrait orientation capabilities with a 0-20 degree tilt. Connectivity includes two HDMI inputs (HDCP 2.2), one DisplayPort in/out, DVI-D, and an Intel SDM slot for built-in signage PCs. The unit weighs approximately 57.8 kg and requires standard 110–240 V AC power. Smart-Boards provides live demonstrations and manages delivery logistics to GCC and African destinations.
Key features
- High Brightness Panel - The 86-inch display offers 1200 cd/m² typical brightness to maintain image clarity in brightly lit commercial and public spaces.
- 24/7 Operational Reliability - Engineered for continuous daily operation, it functions within 0°C to 40°C temperatures and up to 1400 m altitude without degradation.
- Intel SDM Slot Support - An Intel SDM specification slot (SDM-S/SDM-L) allows for the integration of built-in signage computers and additional interface boards.
- Comprehensive Connectivity - Inputs include dual HDMI (HDCP 2.2), DisplayPort, DVI-D, and RS-232C, while two USB 3.0 ports provide power and data access.
- Flexible Orientation - The display supports Landscape and Portrait modes with a tilting angle of 0-20 degrees forward for optimal viewing angles.
Ideal for: High-traffic corporate lobbies, educational institutions, and retail environments across the GCC and Africa requiring bright, durable 4K digital signage.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- TH-86SQ1H
- Key features
- USB Media Player, Failover/Failback, Data Cloning, Digital Zoom, Multi display settings, Power on Screen Delay, Automatic position correction, Screen Saver, Power Management, Power save, Button Lock, Controller user level, Input search, 6-segment col
- Orientation
- Landscape, Portrait
Display
- Backlight
- Direct LED
- Brightness
- 1200 cd/m²
- Colour depth
- 10-bit (1.07 billion colours)
- Resolution
- 4K UHD
- Screen size
- 86"
- Viewing angle
- 178° (H) / 178° (V)
- Aspect ratio
- 16:9
- Contrast ratio
- 1,200:1
- Panel technology
- IPS
- Response time
- 8 ms
System
- Operating hours
- 24/7
Connectivity
- DisplayPort
- DisplayPort (In × 1, Out × 1)
- Ethernet (RJ45)
- RJ45 × 1
- HDMI input
- HDMI In × 2
- Serial port
- RS-232 × 1
- USB ports
- USB-A × 2
Camera & audio
- Audio in
- 3.5 mm audio in × 1
- Audio out
- 3.5 mm audio out × 1
- Speaker output
- 2 × 10 W
Physical & warranty
- In the box
- Remote Control, Batteries (AAA size) × 2, AC cord, Clamper × 3, USB memory cover × 1, SLOT adapter × 1, Operating Instruction Book, Sensor Module × 1, 4-pole micro plug cable (3 m) × 1, Double-sided tape × 2
- Operating humidity
- 20% to 80% RH
- Operating temperature
- 0°C to 40°C
- Power consumption
- 730 W
- Standby power
- ≤ 0.5 W
- Dimensions
- 1929 x 1100 x 96 mm
- Weight
- 57.8 kg
- Shipping dimensions
- 2145 x 1290 x 280 mm
- VESA mount
- 600 x 400 mm
- Bezel size
- 15.5 mm
- Input voltage
- 110–127 V AC, 220–240 V AC, 50/60 Hz
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Can the Panasonic TH-86SQ1H operate continuously?
Yes, this model is designed for 24-hour daily operation, making it suitable for constant display in public areas and busy commercial environments.
Does it support built-in signage PCs?
Yes, the display includes an Intel SDM specification slot that supports standard SDM-S and SDM-L modules for integrated signage solutions.
Is the screen suitable for bright environments?
Yes, with 1200 cd/m² brightness and an anti-glare low reflection surface, it maintains visibility even in brightly lit atriums or near windows.
Can it be installed in Portrait orientation?
Yes, the TH-86SQ1H supports Portrait orientation with a tilting angle of 0-20 degrees forward for flexible mounting configurations.
What is the maximum altitude for operation?
It operates at altitudes up to 1400 m (4593 ft) within 0°C to 40°C; between 1400 m and 2800 m, the temperature range is 0°C to 35°C.
Which countries does Smart-Boards deliver to?
Smart-Boards ships to GCC countries (UAE, KSA, Qatar, Kuwait, Oman, Bahrain) and selected African nations through established logistics partners.
Is on-site installation available outside the UAE?
No, on-site installation is limited to the UAE. Deliveries to other countries arrive ready for local setup, with remote guidance provided if needed.
