The Panasonic TH-75EQ2 is a 75-inch 4K digital signage display designed for high-visibility environments. It features 500 cd/m² brightness, an anti-glare panel, and versatile connectivity including USB-C and HDMI inputs. Smart-Boards supplies this unit across the GCC and Africa with quote-only pricing and logistics support.
This 75-inch Panasonic EQ2 Series display delivers 4K resolution (3840 × 2160) with a contrast ratio of 1200:1. The panel includes anti-glare treatment (Haze 25%) to maintain clarity in bright spaces. With 500 cd/m² brightness, it ensures content remains visible in well-lit conference rooms or reception areas. The 16:9 aspect ratio and 178° viewing angles support flexible installation in either landscape or portrait orientation, allowing seamless integration into modern office or retail environments.
Connectivity options include three HDMI inputs, a PC input, and a USB Type-C port supporting DisplayPort Alternate mode and up to 60W power delivery. The Intel SDM slot enables expansion with wireless presentation or SDI boards. Built-in 20W speakers provide basic audio output. The display supports 18 hours of daily operation and operates within a temperature range of 0°C to 40°C. Smart-Boards offers live demonstrations and on-site installation in the UAE, with delivery ready for local setup in other GCC and African countries.
Key features
- 4K Clarity - The 75-inch panel provides 3840 × 2160 resolution with 500 cd/m² brightness and anti-glare treatment for high visibility in bright rooms.
- Flexible Connectivity - Features three HDMI inputs, USB Type-C with display and power delivery, and an Intel SDM slot for optional expansion boards.
- Versatile Mounting - Supports landscape or portrait orientation with up to 20 degrees tilt, fitting VESA 600 x 400 mm wall mounts with M8 screws.
- Durable Operation - Designed for 18 hours of daily use, operating in temperatures from 0°C to 40°C and altitudes up to 2800 meters.
- Integrated Audio - Includes built-in 20W speakers (10W + 10W) and a stereo mini jack output for external audio connections.
Ideal for: This display suits digital signage, conference rooms, and reception areas for schools, ministries, and companies across the GCC and Africa.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- TH-75EQ2
- Key features
- Wireless Display, USB Media Player, Data Cloning USB, Multi display settings, Power on Screen Delay, Auto setting, No signal power off, HDMI power management (HDMI-Wakeup), Button lock, Operation level control, Set up timer, SERIAL control (RS232C),
- Orientation
- Landscape, Portrait
Display
- Backlight
- Direct LED
- Brightness
- 500 cd/m²
- Colour depth
- 10-bit (1.07 billion colours)
- Resolution
- 4K UHD
- Screen size
- 75"
- Viewing angle
- 178° (H) / 178° (V)
- Aspect ratio
- 16:9
- Contrast ratio
- 1,200:1
- Panel technology
- IPS
- Response time
- 8 ms
System
- Operating hours
- 18 h/day
Connectivity
- DisplayPort
- DisplayPort 1.2a (In × 1, Out × 1)
- Ethernet (RJ45)
- RJ45 × 1
- HDMI input
- HDMI In × 3
- Serial port
- RS-232 × 1
- USB-C
- USB-C × 1
- USB ports
- USB-A × 2, USB-C × 1
- VGA input
- VGA In × 1
- Wi-Fi
- Built-in
Camera & audio
- Audio in
- 3.5 mm audio in × 1
- Audio out
- 3.5 mm audio out × 1, SPDIF out × 1
- Speaker output
- 2 × 10 W
Physical & warranty
- In the box
- Remote Control × 1, IR Sensor × 1, IR Sensor Holder, Screw (for IR Sensor’s Holder) × 2, Power Supply Code, Batteries × 2: AA/R6/LR6 type, Cable Clamper × 3, Spacer × 4, Screw for spacer × 4
- Operating humidity
- 20% to 80% RH
- Operating temperature
- 0°C to 40°C
- Power consumption
- 385 W
- Standby power
- ≤ 0.5 W
- Dimensions
- 1684 x 962 x 96 mm
- Weight
- 37.3 kg
- Shipping dimensions
- 1369 x 874 x 165 mm
- VESA mount
- 600 x 400 mm
- Bezel size
- 14.9 mm
- Input voltage
- 110–240 V AC, 50/60 Hz
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Is the Panasonic TH-75EQ2 available for purchase?
Yes, Smart-Boards is an authorised reseller of Panasonic products. Pricing is provided by quotation only, tailored to your specific requirements and order size.
Which countries in the GCC and Africa can receive this display?
We ship to all GCC countries including UAE, KSA, Qatar, Kuwait, Oman, and Bahrain, as well as various African nations, using established logistics partners for cost-effective delivery.
Does Smart-Boards provide installation for this model?
On-site installation is available within the UAE only. For other countries, the display is delivered ready for local setup, with remote guidance provided if needed.
Can the display be used in portrait mode?
Yes, the TH-75EQ2 supports both landscape and portrait orientations. It can be tilted up to 20 degrees forward or backward for optimal viewing angles.
What is the maximum power consumption?
The display has a maximum power consumption of 385 W. In standby mode, it uses approximately 0.5 W, and in power-off condition, it uses about 0.3 W.
What is the VESA mounting pattern for this screen?
The TH-75EQ2 is VESA compliant with a 600 x 400 mm mounting pitch. It requires M8 screws with a hole depth of 20 mm for secure wall mounting.
Can I get a demonstration before buying?
Yes, Smart-Boards offers both live and virtual demonstrations. Contact our team to schedule a viewing to verify the display's suitability for your space.
