The Panasonic TH-55EQ2 is a 55-inch 4K digital signage display designed for high-visibility environments. It features 500 cd/m² brightness and anti-glare treatment. Smart-Boards supplies this model across the GCC and Africa, offering expert guidance and logistics for multi-site deployments.
This display delivers 3840 × 2160 resolution on a 55-inch panel, ensuring clear content for lobbies and conference rooms. The 500 cd/m² brightness combined with a 25% haze anti-glare surface maintains visibility in bright, sunlit spaces. Its durable construction supports 18 hours of daily operation, making it suitable for continuous information display in busy commercial or educational settings.
Installation flexibility is central to the TH-55EQ2 design, supporting landscape or portrait orientation with a 0-20 degree tilt. It mounts via VESA 400 x 400 mm patterns with M6 screws. Connectivity includes three HDMI inputs, a PC port, and a USB Type-C port supporting DisplayPort Alternate mode and 60W power delivery for simplified device integration.
Key features
- 4K Clarity - Delivers 3840 × 2160 resolution with 500 cd/m² brightness for sharp, visible content in well-lit areas.
- Anti-Glare Panel - Features a 25% haze surface treatment to suppress reflected glare from bright light sources.
- Flexible Connectivity - Includes three HDMI Type A ports, PC In, RS-232C, and a USB Type-C port for video and power.
- SDM Slot - Equipped with an Intel SDM specification slot for optional wireless presentation or signal extension boards.
- Orientation Support - Supports landscape and portrait modes with a 0-20 degree tilt angle for optimal viewing positions.
Ideal for: Suitable for conference rooms, lobbies, and educational spaces across the GCC and Africa where high-brightness displays are required.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- TH-55EQ2
- Key features
- Wireless Display, USB Media Player, Data Cloning USB, Multi display settings, Power on Screen Delay, Auto setting, No signal power off, HDMI power management (HDMI-Wakeup), Button lock, Operation level control, Set up timer, SERIAL control (RS232C),
- Orientation
- Landscape / Portrait
Display
- Backlight
- Direct LED
- Brightness
- 500 cd/m²
- Colour depth
- 10-bit (1.07 billion colours)
- Resolution
- 4K UHD
- Screen size
- 55"
- Viewing angle
- 178° (H) / 178° (V)
- Aspect ratio
- 16:9
- Contrast ratio
- 1,200:1
- Panel technology
- IPS
- Response time
- 8 ms
System
- Operating hours
- 18/7
Connectivity
- DisplayPort
- DisplayPort 1.2a (In × 1, Out × 1)
- Ethernet (RJ45)
- RJ45 × 1
- HDMI input
- HDMI In × 3
- Serial port
- RS-232 × 1
- USB-C
- USB-C × 1
- USB ports
- USB-A × 2
- VGA input
- VGA In × 1
- Wi-Fi
- Built-in
Camera & audio
- Audio in
- 3.5 mm jack × 1
- Audio out
- 3.5 mm audio out × 1, SPDIF out × 1
- Speaker output
- 2 × 10 W
Physical & warranty
- In the box
- Remote Control × 1, IR Sensor × 1, IR Sensor Holder, Screw (for IR Sensor’s Holder) × 2, Power Supply Code, Batteries × 2: AA/R6/LR6 type, Cable Clamper × 3, Spacer × 4, Screw for spacer × 4
- Operating humidity
- 20% to 80% RH
- Operating temperature
- 0°C to 40°C
- Power consumption
- 280 W
- Standby power
- ≤ 0.5 W
- Dimensions
- 1242 x 713 x 66 mm
- Weight
- 18.0 kg
- Shipping dimensions
- 1369 x 874 x 165 mm
- VESA mount
- 400 x 400 mm
- Bezel size
- 13.9 mm (T/R/L/B)
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Is the Panasonic TH-55EQ2 suitable for bright environments?
Yes. It features 500 cd/m² brightness and an anti-glare panel to maintain visibility in bright spaces.
Can I mount the TH-55EQ2 in portrait mode?
Yes. The display supports landscape and portrait orientations with a 0-20 degree tilt angle for flexible installation.
What video inputs are available?
It includes three HDMI Type A connectors, one PC In port, and a USB Type-C port for video input and power delivery.
Can the TH-55EQ2 be used for video conferencing?
Yes. The USB Type-C port allows connection to PCs and peripherals, supporting quick setup for meeting applications.
Which countries does Smart-Boards deliver to?
We ship to GCC and African countries through established logistics partners at the lowest possible cost, with delivery times confirmed on the quotation.
Is installation included outside the UAE?
No. On-site installation is within the UAE only. Other countries receive delivery ready for local setup with remote guidance if needed.
Does the TH-55EQ2 support wireless presentation?
Yes. The Intel SDM slot supports optional receiver boards for wireless presentation systems like Panasonic PressIT.
