The OneScreen Hubware HL7 Education 75" is a 75-inch 4K UHD interactive flat panel featuring a built-in Intel i7 OPS PC, Android 11, a 4K tracking camera, and 40-point infrared touch. Smart-Boards supplies this all-in-one solution for schools and enterprises across the GCC and Africa, including UAE, KSA, and Qatar.
This 75-inch display delivers 4K UHD resolution with 400 nits brightness and a 178° viewing angle, ensuring clarity in large classrooms or meeting rooms. The integrated Intel i7 OPS PC runs Windows 11 with 16 GB RAM and 256 GB storage, while the Android 11 system handles display functions. A 4K UHD camera with 8x digital zoom and presenter tracking supports hybrid collaboration, complemented by an array microphone and dual 16 W stereo speakers.
Connectivity includes Wi-Fi 6, Bluetooth 5.2, three HDMI inputs, USB-C with 65 W PD, and Gigabit Ethernet. The panel features 40-point infrared touch with 1.5 mm accuracy and anti-glare glass. It supports flush wall mounting via a 400 x 200 mm VESA pattern and accepts 100–240 V AC input. Smart-Boards provides this unit with a three-year manufacturer warranty and after-sales support for multi-site deployments across the region.
Key features
- Built-in OPS PC - Includes an Intel i7 Windows 11 PC with 16 GB RAM and 256 GB storage for standalone operation.
- 4K Tracking Camera - Features an 110° field of view camera with 8x digital zoom and auto-framing for video conferencing.
- 40-Point Touch - Uses Gen 2 infrared touch technology with 1.5 mm accuracy and less than 7 ms response time.
- Connectivity Options - Offers Wi-Fi 6, Bluetooth 5.2, three HDMI inputs, USB-C PD, and dual Gigabit Ethernet ports.
- Audio and Mic - Equipped with an array microphone and dual 16 W stereo speakers for clear audio output.
Ideal for: Suitable for smart classrooms, lecture halls, and conference rooms for buyers across the GCC and Africa requiring an all-in-one interactive display with built-in computing and conferencing capabilities.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- Hubware HL7 Education 75
- Product type
- Interactive Flat Panel with Built-in OPS PC and Camera
- Key features
- 75-inch 4K UHD display, 40-point infrared touch, built-in Windows 11 i7 OPS PC, Android 11, 4K tracking camera, array microphone, Wi-Fi 6, 2 × 16 W speakers
Display
- Backlight
- LED
- Blue light filter
- Yes
- Brightness
- 400 cd/m²
- Colour depth
- 1.07 billion colours (10-bit)
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 75"
- Surface protection
- Anti-glare, anti-fingerprint glass
- Viewing angle
- 178°
- Aspect ratio
- 16:9
Touch
- Touch accuracy
- 1.5 mm
- Touch points
- 40-point multi-touch
- Touch response time
- <7 ms
- Touch technology
- Infrared (zero bonding, Gen 2)
System
- Processor
- Quad-core ARM Cortex A55, up to 1.8 GHz (display); Intel i7 (OPS PC)
- Graphics
- Intel Iris Xe Graphics (OPS PC)
- OPS slot
- OneScreen OPS PC (Intel i7) included
- Operating system
- Android 11
- RAM
- 8 GB (display); 16 GB (OPS PC)
- Storage
- 64 GB
Connectivity
- Bluetooth
- Bluetooth 5.2
- Ethernet (RJ45)
- RJ45 × 2 (Gigabit Ethernet)
- HDMI input
- HDMI In × 3 (1 front, 2 side)
- HDMI output
- HDMI Out × 1
- Serial port
- RS-232 × 1
- USB-C
- USB-C × 1 (front, 65 W PD)
- USB ports
- USB 3.0 × 4, USB 2.0 × 1, USB Touch × 2
- VGA input
- VGA In × 1, VGA Audio In × 1
- Wi-Fi
- Wi-Fi 6, 2.4 GHz / 5 GHz
- Ports
- OPS PC: HDMI 1.4 × 1, USB 3.1 × 2, USB 2.0 × 1, USB-C (USB 3.1) × 1, RJ45 × 1, Line-out/Mic-in × 1
Camera & audio
- Audio out
- Audio Out × 1 (3.5 mm)
- Built-in camera
- Yes
- Camera
- 4K UHD tracking camera, 8x digital zoom, 110° field of view, presenter tracking, auto-framing
- Speaker output
- 2 × 16 W stereo
- Microphone
- Array microphone
Physical & warranty
- Mounting type
- Flush wall mount
- In the box
- HDMI cable, power cable, USB touch cable, USB-C cable, 2 stylus pens, display remote control, camera remote control, 2 Wi-Fi/Bluetooth antennas, Logitech wireless keyboard with touchpad
- Power consumption
- 200 W (typical), 360 W (maximum)
- Standby power
- 0.5 W
- Dimensions
- 1709 x 1020 x 88 mm
- Weight
- 47.3 kg
- Shipping dimensions
- 1863 x 1140 x 225 mm
- VESA mount
- 400 x 200 mm
- Warranty
- 3 years
- Shipping weight
- 60.6 kg
- Input voltage
- 100–240 V AC, 50/60 Hz
- Certifications
- FCC, Energy Star, UL, CE, RoHS, WEEE, CB (display only)
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
What is included in the box?
The package contains the display, HDMI cable, power cable, USB touch cable, USB-C cable, two stylus pens, display and camera remotes, two Wi-Fi/Bluetooth antennas, and a Logitech wireless keyboard with touchpad.
Which countries can this be delivered to?
Smart-Boards ships this product to GCC countries including UAE, KSA, Qatar, Kuwait, Oman, and Bahrain, as well as African nations, through established logistics partners to ensure cost-effective delivery.
Is installation available outside the UAE?
On-site installation is provided within the UAE only. For other countries, the unit is delivered ready for local setup, with remote guidance available from the Smart-Boards team if needed.
Does it support wireless connectivity?
Yes, the panel includes built-in Wi-Fi 6 supporting 2.4 GHz and 5 GHz bands, along with Bluetooth 5.2 for connecting peripherals and devices without cables.
What are the power requirements?
The device operates on 100–240 V AC, 50/60 Hz, with typical consumption of 200 W and a maximum of 360 W, making it compatible with standard regional power supplies.
How do I mount this panel?
It supports flush wall mounting using a standard 400 x 200 mm VESA pattern. The unit weighs 47.3 kg, so appropriate wall structures or stands are required for safe installation.
What warranty is provided?
The OneScreen Hubware HL7 Education 75" comes with a three-year manufacturer warranty. Smart-Boards also provides after-sales support for the duration of this coverage period.
