The OneScreen Hubware HL7 Education 55 is a 55-inch interactive flat panel designed for education and business environments. It combines a 4K UHD display with a built-in Intel i7 Windows 11 OPS PC, 40-point infrared touch, and a 4K tracking camera. Smart-Boards supplies this integrated solution to clients across the GCC and Africa.
This unit integrates a 55-inch 4K UHD screen with a slot-in Intel i7 OPS PC running Windows 11, eliminating external box PCs. The display features 40-point infrared touch with 1.5 mm accuracy and 1.07 billion colours. A built-in 4K UHD camera with 8x digital zoom and presenter tracking supports video conferencing, while Wi-Fi 6 and Bluetooth 5.2 ensure robust wireless connectivity for modern classrooms and boardrooms.
Hardware inputs include three HDMI ports, VGA, and two Gigabit Ethernet jacks, alongside a front USB-C port with 65W power delivery. The device includes an array microphone and dual 16W stereo speakers for clear audio. It ships with a Logitech wireless keyboard, stylus pens, and mounting hardware. The panel measures 1271 x 774 mm with an 87 mm depth, weighing 26.1 kg, and carries a three-year manufacturer warranty.
Key features
- Built-in Computing - An Intel i7 OPS PC with Windows 11, 16 GB RAM, and 256 GB storage is included, providing immediate functionality without external computers.
- 4K Tracking Camera - A 4K UHD camera with an 110° field of view and 8x digital zoom offers auto-framing and presenter tracking for professional video calls.
- High-Accuracy Touch - Gen 2 infrared touch technology supports 40 simultaneous touch points with 1.5 mm accuracy and a response time under 7 ms.
- Connectivity Options - Includes Wi-Fi 6, Bluetooth 5.2, two Gigabit Ethernet ports, HDMI In/Out, VGA, and a front USB-C port with 65W power delivery.
- Audio and Input - Features an array microphone, dual 16W stereo speakers, three HDMI inputs, VGA, and multiple USB 3.0 and USB 2.0 ports.
Ideal for schools, universities, and corporate training rooms in the GCC and Africa requiring an all-in-one interactive display with integrated computing and conferencing capabilities.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- Hubware HL7 Education 55
- Product type
- Interactive Flat Panel with Built-in OPS PC and Camera
- Key features
- 55-inch 4K UHD display, 40-point infrared touch, built-in Windows 11 i7 OPS PC, Android 11, 4K tracking camera, array microphone, Wi-Fi 6, 2 × 16 W speakers
Display
- Backlight
- LED
- Blue light filter
- Yes
- Brightness
- 400 cd/m²
- Colour depth
- 1.07 billion colours (10-bit)
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 55"
- Surface protection
- Anti-glare, anti-fingerprint glass
- Viewing angle
- 178°
- Aspect ratio
- 16:9
Touch
- Touch accuracy
- 1.5 mm
- Touch points
- 40-point multi-touch
- Touch response time
- <7 ms
- Touch technology
- Infrared (zero bonding, Gen 2)
System
- Processor
- Quad-core ARM Cortex A55, up to 1.8 GHz (display); Intel i7 (OPS PC)
- Graphics
- Intel Iris Xe Graphics (OPS PC)
- OPS slot
- OneScreen OPS PC (Intel i7) included
- Operating system
- Android 11
- RAM
- 8 GB (display); 16 GB (OPS PC)
- Storage
- 64 GB
Connectivity
- Bluetooth
- Bluetooth 5.2
- Ethernet (RJ45)
- RJ45 × 2 (Gigabit Ethernet)
- HDMI input
- HDMI In × 3 (1 front, 2 side)
- HDMI output
- HDMI Out × 1
- Serial port
- RS-232 × 1
- USB-C
- USB-C × 1 (front, 65 W PD)
- USB ports
- USB 3.0 × 4, USB 2.0 × 1, USB Touch × 2
- VGA input
- VGA In × 1, VGA Audio In × 1
- Wi-Fi
- Wi-Fi 6, 2.4 GHz / 5 GHz
- Ports
- OPS PC: USB 3.0 × 2, USB 2.0 × 2, USB-C × 1, Mic In × 1, Earphone Out × 1, HDMI × 1, RJ45 × 1
Camera & audio
- Audio out
- Audio Out × 1 (3.5 mm)
- Built-in camera
- Yes
- Camera
- 4K UHD tracking camera, 8x digital zoom, 110° field of view, presenter tracking, auto-framing
- Speaker output
- 2 × 16 W stereo
- Microphone
- Array microphone
Physical & warranty
- Mounting type
- Flush wall mount
- In the box
- HDMI cable, power cable, USB touch cable, USB-C cable, 2 stylus pens, display remote control, camera remote control, 2 Wi-Fi/Bluetooth antennas, Logitech wireless keyboard with touchpad
- Power consumption
- 160 W (typical), 320 W (maximum)
- Dimensions
- 1271 x 774 x 87 mm
- Weight
- 26.1 kg
- Shipping dimensions
- 1401 x 859 x 220 mm
- VESA mount
- 400 x 200 mm
- Warranty
- 3 years
- Shipping weight
- 34.5 kg
- Input voltage
- 100–240 V AC, 50/60 Hz
- Certifications
- RoHS, FCC (display only)
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Does the OneScreen Hubware HL7 Education 55 include an operating system?
Yes, it runs Android 11 on the display and comes with a slot-in OPS PC pre-installed with Windows 11, an Intel i7 processor, 16 GB RAM, and 256 GB storage.
Can this panel be delivered to multiple countries in Africa or the GCC?
Yes, Smart-Boards ships to GCC and African countries through established logistics partners at the lowest possible cost. Delivery time depends on the country and order size and is confirmed on the quotation.
Is on-site installation available outside the UAE?
On-site installation is provided within the UAE only. For other countries, the device is delivered ready for local setup with remote guidance if needed to assist your technical team.
What is the screen resolution and touch technology?
The screen resolution is 3840 x 2160 (4K UHD). It uses Gen 2 infrared touch technology that supports 40-point multi-touch with 1.5 mm accuracy and a response time of less than 7 ms.
Does it support wireless connectivity standards?
Yes, the unit includes Wi-Fi 6 supporting both 2.4 GHz and 5 GHz bands, as well as Bluetooth 5.2 for connecting peripherals and wireless presentations.
What accessories are included in the box?
The package includes an HDMI cable, power cable, USB touch cable, USB-C cable, two stylus pens, display and camera remote controls, two Wi-Fi/Bluetooth antennas, and a Logitech wireless keyboard with touchpad.
What is the warranty coverage for this model?
The OneScreen Hubware HL7 Education 55 comes with a manufacturer warranty of three years. Smart-Boards also provides after-sales support for clients across the GCC and Africa.
