The OneScreen Hubware H7 Education 86 is an 86-inch interactive flat panel designed for educational and corporate environments in the GCC and Africa. It features 4K UHD resolution, a built-in 8-array microphone, and Android 15 OS. Smart-Boards, an authorised reseller based in Dubai, supplies this model with regional logistics and installation services.
This 86-inch display delivers a 3840 x 2160 4K UHD image with 450 nits brightness and a 4,000:1 contrast ratio. The zero-bonding infrared touch layer supports up to 50 points of simultaneous contact with 1 mm accuracy. A built-in 8-array microphone with noise reduction ensures clear audio capture for hybrid learning or meetings.
The panel runs Android 15 with EDLA certification, powered by an octa-core processor and 8 GB of RAM. Connectivity includes four HDMI inputs, three Type-C ports (one 100 W front), and Wi-Fi 6E. An OPS slot allows for additional PC expansion. The unit weighs 63.0 kg and supports VESA 800 x 600 mm mounting.
Key features
- 50-Point Touch - Infrared touch technology supports up to 50 simultaneous touch points with 1 mm accuracy and a response time of less than 2.5 ms.
- Android 15 OS - The built-in operating system provides Android 15 with EDLA, featuring an octa-core processor, 8 GB RAM, and 128 GB storage.
- Audio Integration - Integrated audio includes two 20 W speakers, a 25 W subwoofer, and an 8-array microphone with noise reduction for clear voice pickup.
- Connectivity Ports - Includes four HDMI inputs, three Type-C ports (100 W front), four USB 3.0 ports, and an OPS slot for flexible device integration.
- Network Capabilities - Equipped with Wi-Fi 6E, Bluetooth 5.3, and dual RJ45 Ethernet ports (10/100/1000 Mbps) for reliable wired and wireless networking.
Ideal for: Classrooms, lecture halls, and corporate meeting rooms requiring large-format interaction, suitable for buyers across the GCC and Africa.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- Hubware H7 Education 86
- Product type
- Interactive Flat Panel
- Key features
- 50-point touch, Android 15, 8-array microphone, NFC login, OPS slot, Wake-on-LAN, ambient light sensor, 25 W subwoofer
Display
- Backlight
- DLED
- Brightness
- 450 cd/m²
- Colour depth
- 1.07 billion colours
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 86"
- Surface protection
- Anti-glare, anti-fingerprint, 9H hardness
- Viewing angle
- 178° (H/V)
- Colour gamut
- 72% NTSC
- Contrast ratio
- 4,000:1
Touch
- Touch accuracy
- 1 mm
- Touch points
- Up to 50-point multi-touch
- Touch resolution
- 32768 x 32768
- Touch response time
- < 2.5 ms
- Touch technology
- Infrared (zero bonding, Gen2)
System
- Processor
- Octa-core (4x A76 + 4x A55)
- Graphics
- Mali-G610 MP4
- OPS slot
- 1 × OPS PC slot
- Operating system
- Android 15
- RAM
- 8 GB
- Storage
- 128 GB
Connectivity
- Bluetooth
- Bluetooth 5.3
- DisplayPort
- DisplayPort 1.2 × 1
- Ethernet (RJ45)
- RJ45 × 2 (In/Out, 10/100/1000 Mbps)
- HDMI input
- HDMI In × 4 (1 front, 3 side)
- HDMI output
- HDMI Out × 1
- Serial port
- RS-232 × 1
- Touch USB ports
- USB 2.0 × 2
- USB-C
- Type-C In × 3 (front 100 W, side 15 W, top), Type-C Out × 1 (rear, 4K @ 60 Hz)
- USB ports
- USB 3.0 × 4 (2 front, 2 side), USB 2.0 × 1 (side)
- Wi-Fi
- Wi-Fi 6E (2.4 GHz, 5 GHz, 6 GHz)
Camera & audio
- Audio in
- 3.5 mm × 1
- Audio out
- 3.5 mm × 1, SPDIF × 1
- Speaker output
- 2 × 20 W + 25 W subwoofer
- Speaker configuration
- 2 built-in speakers (L/R) + subwoofer
- Microphone
- Built-in 8-array microphone with noise reduction
Physical & warranty
- In the box
- HDMI cable, power cable, USB touch cable, 2 stylus pens, remote control, whiteboard magnetic eraser, 5 NFC cards
- Operating humidity
- 10% to 90% RH
- Operating temperature
- 0 to 40 °C
- Power consumption
- 315 W (typical), 530 W (maximum)
- Standby power
- 0.5 W
- Dimensions
- 1956 x 1179 x 69 mm
- Weight
- 63.0 kg
- Shipping dimensions
- 2111 x 1303 x 226 mm
- VESA mount
- 800 x 600 mm (flush wall mount)
- Shipping weight
- 83.3 kg
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Does this panel support multi-touch?
Yes, it supports up to 50 points of simultaneous touch using zero-bonding infrared technology with 1 mm accuracy.
Is an OPS PC included?
No, the OPS slot is empty. You can add a compatible OPS PC separately or use the built-in Android 15 system.
Which countries does Smart-Boards deliver to?
We ship to UAE, KSA, Qatar, Kuwait, Oman, Bahrain, and African countries through established logistics partners at the lowest possible cost.
Do you provide installation outside the UAE?
No, on-site installation is within the UAE only. Other countries receive delivery ready for local setup with remote guidance if needed.
What is the screen resolution?
The resolution is 3840 x 2160 (4K UHD) with 450 nits brightness and a 178° viewing angle.
What is the power consumption?
Typical power consumption is 315 W, with a maximum of 530 W and 0.5 W standby power.
How do you price this product?
Pricing is by quotation only. We offer education, government, bulk, and tender options upon request.
