The OneScreen Hubware H3 84 is an 84-inch interactive flat panel featuring a 4K UHD display and an integrated Intel Core i7 OPS PC. Designed for large conference rooms, it includes a PTZ camera and speakerphone. Smart-Boards supplies this solution across the GCC and Africa, with quotation-based pricing and regional logistics support.
This 84-inch interactive display delivers 4K UHD resolution with a 120 Hz refresh rate and 178° viewing angles, ensuring clarity in large meeting spaces. The integrated OPS slot houses an Intel Core i7 processor with 8 GB RAM and 128 GB SSD, running Windows 8.1 Professional for instant access to productivity tools without external devices.
Communication is enhanced by the included OneScreen PTZ camera with 12x optical zoom and the CHAT 150 speakerphone with omni-directional microphones. The system supports H.323, SIP, and WebRTC protocols for video conferencing, allowing connections with up to four cameras. Built-in Wi-Fi and gigabit Ethernet provide flexible connectivity options for diverse network environments.
Key features
- Integrated OPS Computing - Features an Intel Core i7 processor, 8 GB RAM, and 128 GB SSD within the OPS slot for direct operation without external PCs.
- Video Conferencing Kit - Includes a PTZ camera with 12x optical zoom and a CHAT 150 speakerphone for high-quality audio and visual collaboration.
- 4K Interactive Display - Delivers 3840 x 2160 resolution with 10-point infrared touch accuracy of ±1.5 mm and a 17 ms response time.
- Network Protocols - Supports SIP, H.323, H.329, WebRTC, and VISCA protocols for integration with existing conferencing infrastructure.
- Connectivity Options - Equipped with three HDMI inputs, VGA, RS-232, RJ45 gigabit Ethernet, and built-in 802.11 a/b/g/n Wi-Fi.
- Audio Output - Features two built-in 10 W speakers configured for left and right channel output to provide clear sound in meeting rooms.
Ideal for: Suitable for executive boardrooms and large training centers requiring integrated video conferencing, suitable for buyers across the GCC and Africa managing multi-site AV deployments.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- Hubware H3 84
- Product type
- Interactive Flat Panel with OPS PC
- Key features
- 10-point infrared touch, Intel Core i7 OPS PC, PTZ camera and speakerphone, built-in OneScreen video conferencing, SIP/H.323 and WebRTC, up to 4 cameras, Wi-Fi and gigabit LAN, 10 W + 10 W speakers
- Conference calling
- H.323/SIP video services, WebRTC, up to 4 cameras
- Protocols
- SIP, H.323, H.329, WebRTC, LDAP/AD, HTTPS, RTSP, VISCA
Display
- Refresh rate
- 120 Hz
- Resolution
- 4K UHD
- Screen size
- 84"
- Viewing angle
- 178°
- Aspect ratio
- 16:9
- Contrast ratio
- 1,400:1
Touch
- Touch accuracy
- ±1.5 mm
- Touch points
- 10-point multi-touch
- Touch response time
- 17 ms
- Touch technology
- Infrared
- Touchscreen
- Yes, writes with finger or any solid object
System
- Processor
- Intel Core i7 (OPS PC); quad-core (Android)
- OPS slot
- 80-pin OPS port
- Operating system
- Android 4
- RAM
- 8 GB
- Storage
- 128 GB
- Memory type
- DDR3
Connectivity
- Ethernet (RJ45)
- RJ45; 10/100/1000 Mbps (OPS PC)
- HDMI input
- 3
- USB ports
- USB 3.0 × 1, USB 2.0 × 2 (display); USB 3.0 × 2, USB 2.0 × 2 (OPS PC)
- VGA input
- 1
- Wi-Fi
- Built-in 802.11 a/b/g/n
- Ports
- HDMI In × 3, VGA × 1, RS-232 × 1, RJ45 × 1, YPbPr × 1, AV Out × 1, headphone × 1, SD card reader × 1, RF In × 1, touch USB × 1
- Connectivity options
- Ethernet, built-in Wi-Fi (802.11 a/b/g/n)
Camera & audio
- Built-in camera
- Yes
- Camera
- OneScreen PTZ camera VHD-V61U, 12x optical zoom, 72.5° horizontal view, 170° pan
- Speaker output
- 10 W + 10 W
- Speaker configuration
- 2 built-in speakers, left and right
- Microphone
- CHAT 150 speakerphone with omni-directional full-duplex microphones
Physical & warranty
- In the box
- Monitor remote control, camera remote control, Logitech K400 wireless keyboard, PTZ camera with speakerphone
- Dimensions
- 1943 x 1156 x 84 mm (excludes top-mounted camera)
- Weight
- 101.6 kg
- Shipping dimensions
- 2159 x 1422 x 254 mm
- Warranty
- 1 year standard (advanced hardware warranty optional)
- Shipping weight
- 149.7 kg
- Input voltage
- 100–240 V AC, 50/60 Hz
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Is the OneScreen Hubware H3 84 currently available for purchase?
This model is discontinued. Smart-Boards can confirm current availability or recommend the current successor model that meets your specifications and budget requirements for GCC and African deployments.
Which countries does Smart-Boards deliver to?
Smart-Boards ships to GCC countries (UAE, KSA, Qatar, Kuwait, Oman, Bahrain) and various African nations through established logistics partners, ensuring cost-effective delivery to your location.
Is installation service included outside the UAE?
On-site installation is available within the UAE only. For other countries, units are delivered ready for local setup with remote guidance provided by the Smart-Boards technical team if needed.
Does this panel include a PTZ camera?
Yes, the package includes the OneScreen PTZ camera VHD-V61U with 12x optical zoom and a 72.5° horizontal view, along with a dedicated camera remote control for pan and tilt adjustments.
What operating systems does the OPS PC support?
The integrated OPS PC runs Windows 8.1 Professional. The display itself operates on Android 4.2.2, allowing for standalone touch functionality and app usage without the OPS module.
Can the system connect to multiple cameras?
Yes, the built-in video conferencing engine supports H.323, SIP, and WebRTC, allowing connections to up to four cameras simultaneously for flexible large-room setups.
What warranty coverage is provided?
The product comes with a 1-year standard manufacturer warranty. Smart-Boards also offers advanced hardware warranty options and comprehensive after-sales support for all regions.
