The LG 55TNF5P is a 55-inch UHD touch open frame digital signage kiosk built for high-traffic commercial environments. It features an IPS panel with 450 nits brightness and built-in webOS 6.0 for local content scheduling. Smart-Boards supplies this unit for multi-site deployments across the GCC and Africa.
This open frame design integrates seamlessly into custom enclosures or wall mounts, offering a 55-inch UHD display with 1,000:1 contrast and 178-degree viewing angles. The IPS panel ensures consistent color accuracy across its 1.07 billion color depth, supporting 24/7 operation with a 50,000-hour backlight life. Built-in sensors monitor temperature and acceleration, while webOS 6.0 provides robust media playback capabilities without external players.
Smart-Boards provides this LG model for enterprises, educational institutions, and government bodies across the GCC and Africa. The unit supports HDMI, RS232C, and LAN control, ensuring compatibility with existing AV infrastructure. We facilitate logistics from our Dubai office, handling delivery to multiple countries and offering on-site installation within the UAE only. Remote guidance is available for international setups to ensure successful deployment.
Key features
- UHD Touch Display - Features a 55-inch IPS panel with 3,840 x 2,160 resolution, 450 nits brightness, and 12-haze surface treatment for clear touch interaction.
- webOS 6.0 Platform - Runs on webOS 6.0 with 8GB internal memory, enabling local content scheduling, group management, and gapless video playback.
- Commercial Connectivity - Includes dual HDMI inputs with HDCP 2.2/1.4, RS232C, RJ45 LAN, and USB 2.0 ports for flexible device integration and control.
- 24/7 Durability - Rated for 24-hour daily operation with a 50,000-hour minimum backlight life, operating reliably between 0°C and 40°C.
- Management Integration - Supports SNMP, Control Manager, and Cisco/Crestron certification for centralized monitoring and control in large-scale deployments.
Ideal for corporate lobbies, educational campuses, and government service centers requiring durable, interactive digital signage, suitable for buyers managing multi-site rollouts across the GCC and Africa.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Included cables
- Power Cord × 1, USB Cable (Type A-Type B) × 1
- Key features
- Wake on LAN, Sensors: Temperature, Acceleration (gyro)
- Orientation
- Portrait / Landscape
Display
- Backlight
- IPS
- Brightness
- 450 cd/m²
- Colour depth
- 10-bit (1.07 billion colours)
- Resolution
- 4K UHD
- Screen size
- 55"
- Viewing angle
- 178° (H) / 178° (V)
- Colour gamut
- NTSC 72%
- Contrast ratio
- 1,000:1
- Panel technology
- IPS
- Response time
- 9 ms
Touch
- Touch accuracy
- 3.5 mm
- Touch points
- 10 Points Multi Touch
- Touch response time
- 90 ms
System
- Operating system
- webOS 6
- Sensors
- Temperature, Acceleration (Gyro)
- Storage
- 8 GB
- Operating hours
- 24/7
Connectivity
- Ethernet (RJ45)
- RJ45 × 1
- HDMI input
- HDMI In × 2
- Serial port
- RS232 × 1
- Touch USB ports
- USB 2.0 Type B × 1
- USB ports
- USB 2.0 Type A × 1
- Wake-on-LAN
- Yes
Camera & audio
- Audio out
- Audio Out × 1
Physical & warranty
- In the box
- Power Cord × 1, USB Cable (Type A-Type B) × 1, User Manual, QSG, Remote Controller (include battery 2ea), RS232C Gender, IR Receiver
- Operating humidity
- 10%~80% RH
- Operating temperature
- 0 °C to 40 °C
- Power consumption
- < 170 W
- Standby power
- ≤ 0.5 W
- Dimensions
- 1231.8 × 709.6 × 39.2 mm
- Weight
- 16.8 kg
- Shipping dimensions
- 1360 × 835 × 175 mm
- VESA mount
- 300 × 300 mm (VESA)
- Bezel size
- 9.1 / 9.1 / 9.1 / 16.1 mm (T/R/L/B)
- Input voltage
- 100–240 V AC, 50/60 Hz
- Certifications
- CB / NRTL, FCC Class A, CE, KC, Energy Star
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
What is the native resolution of the LG 55TNF5P?
The LG 55TNF5P has a native UHD resolution of 3,840 x 2,160 pixels, providing sharp text and detailed images for digital signage applications.
Can this kiosk operate continuously?
Yes, the LG 55TNF5P is designed for 24/7 commercial operation, featuring a 50,000-hour minimum backlight lifespan and built-in thermal management.
Which countries receive delivery?
Smart-Boards delivers to GCC countries (UAE, KSA, Qatar, Kuwait, Oman, Bahrain) and select African nations via established logistics partners, with costs optimized for each region.
Is on-site installation available outside the UAE?
On-site installation is provided within the UAE only. For other countries, units are delivered ready for local setup, with remote guidance available to assist your technical team.
Does it support network control?
Yes, the unit supports SNMP, Control Manager, and LAN connectivity, allowing centralized monitoring and configuration of multiple displays from a single interface.
What operating system is used?
The LG 55TNF5P runs on webOS 6.0, which includes features like local content scheduling, group manager, and USB plug-and-play for easy media updates.
What is the bezel width?
The open frame design has variable bezel widths: 9.1mm on the top, left, and right sides, and 16.1mm on the bottom, allowing for flexible mounting options.
