The LG 55SVM5F-H is a 55-inch Full HD video wall panel featuring a 0.44mm slim bezel and 500-nit brightness for clear visual impact. Designed for continuous operation, it supports portrait and landscape orientations with OPS compatibility. Smart-Boards supplies this display for multi-site projects across the GCC and Africa.
This 55-inch display utilises an IPS panel to deliver a 1920 x 1080 resolution with a 1,100:1 contrast ratio and 178-degree viewing angles. The 0.44mm even bezel enables tight tiling for seamless imagery, while the slim 86.5mm profile ensures a clean aesthetic for corporate lobbies, control rooms, or educational environments. It operates continuously at 200W typical power consumption.
Connectivity includes dual HDMI, DisplayPort, and DVI-D inputs alongside RS232C and LAN ports for centralised management. The unit supports SuperSign CMS for content scheduling and accepts OPS modules for enhanced processing capabilities. We provide quote-based pricing for bulk orders, with logistics tailored to power standards and installation requirements in target countries.
Key features
- Slim Bezel Design - Features a 0.44mm even bezel for tight tiling and minimal visual disruption in large-scale video wall configurations.
- IPS Panel Technology - Uses an IPS panel to maintain consistent colour and image quality across 178-degree horizontal and vertical viewing angles.
- Operational Flexibility - Supports both portrait and landscape orientations with 24-hour duty cycle capability for continuous professional use.
- Management Connectivity - Includes RS232C and RJ45 LAN ports for centralised control, alongside HDMI, DisplayPort, and DVI-D input options.
- OPS Compatibility - Accepts piggyback OPS modules for enhanced processing power, supporting SuperSign CMS for dynamic content management.
Ideal for corporate headquarters, university lecture halls, and government centres across the GCC and Africa requiring durable, high-brightness visual displays for multi-site rollouts.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- 55SVM5F-H
- Product type
- Video Wall Display
- Key features
- 0.44 mm even bezel, 16:9 narrow-bezel tiling, Portrait and landscape orientation, OPS-compatible (piggyback), SuperSign CMS support, RS232C and LAN control, Built-in power
- Orientation
- Portrait & Landscape
Display
- Brightness
- 500 cd/m²
- Resolution
- Full HD
- Screen size
- 55"
- Viewing angle
- 178 x 178
- Aspect ratio
- 16:9
- Contrast ratio
- 1,100:1
- Panel technology
- IPS
- Response time
- 8 ms
System
- Operating hours
- 24 hours a day
Connectivity
- Ports
- HDMI In × 2, DisplayPort In × 1, DVI-D In × 1, USB 2.0 × 1, RS232C In/Out, RJ45 (LAN) In/Out, IR In
Physical & warranty
- In the box
- Remote controller, power cord, RS232C cable, LAN cable, DP cable, IR receiver, guide bracket, screws, manual
- Operating humidity
- 10% to 80% RH
- Operating temperature
- 0 to 40 °C
- Power consumption
- 200 W (typical), 250 W (maximum)
- Standby power
- 105 W (Smart Energy Saving)
- Dimensions
- 1210.51 x 681.22 x 86.5 mm
- Weight
- 16.8 kg
- VESA mount
- 600 x 400 mm
- Input voltage
- 100–240 V AC, 50/60 Hz
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Can this video wall be delivered to countries outside the UAE?
Yes. We ship to GCC and African countries through established logistics partners at the lowest possible cost. Delivery times depend on the specific country and order size, which is confirmed on the quotation.
Is on-site installation included for deliveries outside the UAE?
On-site installation is available within the UAE only. For other countries, units are delivered ready for local setup, with remote guidance provided if needed to assist with configuration and initial operation.
Does the unit support vertical orientation?
Yes. The LG 55SVM5F-H supports both portrait and landscape orientations, allowing flexible configuration for different architectural spaces and visual requirements.
What is the brightness level of this display?
The display offers 500 nits of brightness, ensuring clear visibility in well-lit environments typical of corporate lobbies and educational facilities.
How is content managed on this video wall?
It supports SuperSign CMS for content scheduling and management. Centralised control is also possible via RS232C and LAN ports for integration into existing AV infrastructure.
Is a demonstration available before purchase?
Yes. We offer live or virtual demonstrations before purchase to ensure the display meets your specific technical and visual requirements.
What warranty coverage is provided?
The product comes with the manufacturer warranty plus Smart-Boards after-sales support. We are an authorised reseller of LG, ensuring genuine parts and service access.
