The iiyama ProLite T5529AS-B1AG is a 55-inch all-in-one PCAP interactive display designed for smart collaboration spaces. It features a 4K UHD panel, 20-point touch capability, and an integrated Android 14 operating system for standalone operation. Smart-Boards supplies this unit across the GCC and Africa.
This 54.6-inch interactive flat panel combines a VA DLED screen with DeepContrast PCAP touch technology for precise, multi-user input. The edge-to-edge glass construction offers durability with 8H hardness, while the fanless design ensures quiet operation in huddle rooms and breakout spaces. The device supports 20 touch points via USB, enabling smooth writing and palm rejection for effective brainstorming sessions.
Built on Android 14, the ProLite T5529AS-B1AG runs iiSignage² for digital signage, iiControl for device management, and iiShare for wireless presentation. Connectivity is streamlined through two HDMI inputs and a USB-C port with DP 1.2 Alt mode and 15W power delivery. The USB-C loop-through feature allows daisy-chaining multiple displays, reducing cable clutter in multi-screen deployments across offices or schools.
Key features
- 4K UHD Panel - The display delivers a native resolution of 3840 x 2160 with 500 cd/m² brightness and a 4000:1 static contrast ratio for clear visuals.
- PCAP Touch - DeepContrast PCAP technology supports 20 simultaneous touch points with +/- 2.5mm accuracy using fingers or stylus.
- Android 14 OS - The integrated operating system allows direct app installation and runs iiSignage², iiControl, and iiShare for content and device management.
- USB-C Connectivity - A USB-C input provides video, data, and 15W power, with loop-through capability to connect additional displays via a single cable.
- Multimedia Support - The panel includes two HDMI 2.0 inputs, dual 10W speakers, and USB 2.0 ports for multimedia playback and peripheral connection.
- Durable Design - The unit features an edge-to-edge anti-glare glass surface with 3.7mm thickness and 8H hardness, housed in a metal bezel.
Ideal for: Suitable for huddle rooms, innovation hubs, and educational breakout spaces, this display supports buyers across the GCC and Africa seeking flexible collaboration tools.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- T5529AS-B1AG
- Key features
- Edge to edge glass, Anti-Glare Glass with Anti-Gloss treatment, Smooth writing, Zero Gap - Air Bonde, DeepContrast PCAP, USB-C Loop Through, iiSignage², iiControl, iiShare, EShare, Fanless design, Magnetic holding places for Touch pens
- Orientation
- Landscape, portrait
Display
- Backlight
- Direct LED
- Blue light filter
- Yes
- Brightness
- 450 cd/m²
- Colour depth
- 10-bit (1.07 billion colours)
- Resolution
- 4K UHD
- Screen size
- 55"
- Viewing angle
- 178° (H) / 178° (V)
- Aspect ratio
- 16:9
- Contrast ratio
- 4,000:1
- Panel technology
- VA
- Response time
- 6.5 ms
Touch
- Touch accuracy
- ±2.5 mm
- Touch points
- 20-point multi-touch
- Touch technology
- PCAP
System
- Processor
- MediaTek MT9679
- Operating system
- Android 14
- RAM
- 4 GB
- Storage
- 32 GB
- Operating hours
- 24/7
Connectivity
- Ethernet (RJ45)
- RJ45 × 1
- HDMI input
- HDMI In × 2
- Serial port
- RS-232 × 1
- USB-C
- USB-C × 1
- USB ports
- USB 2.0 × 2
- Wi-Fi
- Built-in
Camera & audio
- Speaker output
- 2 × 10 W
Physical & warranty
- In the box
- Power cable, HDMI cable, RS-232C cable, Touch pen × 2, Quick start guide, Safety guide, Wall Mounting Bracket, Remote control (batteries included)
- Operating temperature
- 0°C to 40°C
- Power consumption
- 104 W
- Standby power
- 0.5 W
- Dimensions
- 1258.2 x 728.8 x 42.3 mm
- Weight
- 26.8 kg
- Shipping dimensions
- 1400 x 850 x 164 mm
- VESA mount
- 300 x 400 mm
- Certifications
- CB, CE, TÜV-Bauart, EAC, RoHS, ErP, WEEE, REACH, UKCA, cTUVus
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
What operating system does the ProLite T5529AS-B1AG use?
It runs Android 14, allowing direct installation of productivity and signage applications without external computers.
Does the display support wireless screen sharing?
Yes, the integrated EShare app enables multi-user wireless presentation and real-time ideation from mobile devices.
Can this unit be used for digital signage?
Yes, it includes iiSignage² CMS for remote content management and supports 24/7 operation with anti-image retention technology.
Which countries can receive delivery?
Smart-Boards ships to all GCC nations (UAE, KSA, Qatar, Kuwait, Oman, Bahrain) and select African countries via established logistics partners.
Is on-site installation available outside the UAE?
On-site installation is provided within the UAE only. Other countries receive the unit ready for local setup, with remote guidance if needed.
What is the touch technology used?
It uses DeepContrast PCAP touch glass, which supports 20 touch points and offers palm rejection for accurate writing and drawing.
How does the USB-C feature work?
The USB-C port supports video input and 15W power delivery, with loop-through capability to daisy-chain additional displays for cleaner setups.
