The Elo Edge Connect Conference Camera (model E277819) is a discontinued Full HD video conferencing unit designed for huddle rooms and meeting spaces. It features a fixed-focus 1080p sensor and an analog microphone with echo cancellation. Smart-Boards, an authorised reseller, manages the supply of current successors and replacement units across the GCC and African regions.
This compact camera delivers 1920 x 1080 video at 30 fps with an 80-degree horizontal field of view, ensuring clear coverage for small to medium seating arrangements. It connects via Micro USB and includes a 2.5 mm jack for its analog microphone with acoustic echo cancellation. The device supports UVC 1.1 protocols, maintaining compatibility with Windows, macOS, Android, and Linux systems without requiring proprietary drivers.
The unit attaches securely to any side of compatible Elo displays using the Edge Connect mounting system, eliminating the need for separate stands or cables. While this specific model has been replaced by the 4K Conference Camera, Smart-Boards offers tailored solutions for buyers in the UAE, KSA, Qatar, and other targeted markets. Our team provides live demonstrations and guides clients toward the appropriate modern equivalent based on their room size and integration needs.
Key features
- Video Performance - Captures Full HD 1920 x 1080 video at 30 frames per second with fixed focus and automatic white balance for consistent image quality.
- Audio Integration - Includes an analog microphone with acoustic echo cancellation, connected via a 2.5 mm barrel jack to reduce background noise during calls.
- Mounting System - Utilizes the Elo Edge Connect interface to attach directly to the left, right, top, or bottom of compatible Elo interactive displays.
- Physical Dimensions - Measures 471.1 x 81.72 x 102.81 mm and weighs 0.36 kg, allowing for a low-profile installation that does not obstruct the screen.
- System Compatibility - Works with Windows 7/10, macOS X 10.4.8+, Android 4.0+, and Linux systems using standard UVC 1.1 driver support.
Ideal for: Small to medium conference rooms and huddle spaces requiring a plug-and-play video solution, suitable for educational and corporate buyers across the GCC and Africa seeking reliable AV integration.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- Edge Connect Conference Camera
- Product type
- Conference Camera
- Key features
- Full HD 1920 x 1080 at 30 fps, 80° horizontal field of view, analog mic with echo cancellation, UVC 1.1, Edge Connect mount, automatic exposure and white balance
- Compatibility
- Windows 7/10, macOS X 10.4.8+, Android 4.0+, Linux with UVC
- Connector type
- Micro USB (USB 2.0) with 2.5 mm jack for AEC
Display
- Resolution
- Full HD
- Viewing angle
- 80° horizontal / 65° vertical / 96° diagonal (±5%)
Camera & audio
- Camera
- 1920 x 1080 at 30 fps, fixed focus
- Microphone
- Analog with acoustic echo cancellation (AEC)
Physical & warranty
- Mounting type
- Elo Edge Connect, attaches to any side of an Elo display
- In the box
- Elo conference camera, 2 M3 mounting screws, 2.5 mm barrel jack cable, quick install guide
- Dimensions
- 471.1 x 81.72 x 102.81 mm
- Weight
- 0.36 kg (unpackaged)
- Warranty
- 3 years
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Is the Elo E277819 still in production?
No, the Elo Edge Connect Conference Camera (E277819) is discontinued. It has been replaced by the 4K Conference Camera. Smart-Boards can confirm availability of remaining stock or recommend the current successor model based on your specific requirements and site specifications.
Which countries in the GCC and Africa can receive this product?
Smart-Boards ships to all GCC countries including the UAE, KSA, Qatar, Kuwait, Oman, and Bahrain, as well as select African nations. We utilize established logistics partners to ensure cost-effective delivery. Delivery times vary by country and order size, which is confirmed during the quotation process.
Does Smart-Boards provide installation for this camera?
On-site installation services are available within the UAE only. For deliveries to other GCC and African countries, the product arrives ready for local setup. We provide remote guidance and technical support to assist your team with the physical attachment and software configuration during deployment.
What is included in the box?
The package contains the Elo conference camera, two M3 mounting screws for the Edge Connect interface, a 2.5 mm barrel jack cable for the microphone, and a quick install guide. A three-year manufacturer warranty covers defects, supported by Smart-Boards' after-sales service.
Can I use this camera with non-Elo displays?
The Edge Connect mount is designed specifically for Elo interactive flat panels. For use with other displays, you would need a standard VESA mount or a separate camera arm, which is not included. The camera connects via Micro USB, so it functions independently of the display once mounted.
What are the viewing angles of this camera?
The camera offers an 80-degree horizontal field of view and a 65-degree vertical field of view, with a diagonal angle of 96 degrees. These angles are designed to cover typical huddle room configurations, ensuring all participants are captured clearly from standard seating positions.
How do I get a price for this or the successor model?
Pricing is provided by quotation only. Smart-Boards offers quote-only pricing with options for education, government, bulk, and tender requirements. Please contact our team for a tailored quote, including logistics costs to your specific country and any applicable warranty or support packages.
