The BenQ Board Master RM6504 is a 65-inch UHD 3840 × 2160 interactive flat panel designed for collaborative environments. Featuring 40-point IR touch, 8-microphone array, and Nano-ionic silver germ-resistant coating, it supports multi-site rollouts. Smart-Boards supplies this Google EDLA-certified device across the GCC and Africa.
This 65-inch display delivers UHD 3840 × 2160 resolution on an IPS panel with 450 nits brightness and 1200:1 contrast. It supports 40 simultaneous touch points via high-precision IR with < 5 ms response time. The integrated 8-microphone array captures audio up to 8 m, while dual 20 W speakers provide clear output. Flicker-free and low blue light technology ensures visual comfort during extended 18-hour daily operation cycles.
Connectivity includes DisplayPort 1.2a, VGA, S/PDIF optical, RS-232, and two Ethernet ports. USB-C supports 65 W power delivery, with five USB 3.0 and two USB 2.0 ports available. An OPS slot accommodates slot-in PCs, and optional Wi-Fi 6 and Bluetooth 5.2 enhance wireless capabilities. The unit features NFC, ambient light, and IR sensors for automated adjustments. DMS and AMS software enable remote device and account management for centralized administration.
Key features
- High Precision Touch - Supports up to 40 touch points with < 5 ms response time using IR technology on the 65-inch panel.
- Audio & Video Input - Includes DisplayPort, VGA, S/PDIF, RS-232, dual Ethernet, and an OPS slot for slot-in PC integration.
- USB-C Power Delivery - Features one USB-C 3.0 port delivering 65 W power alongside five USB 3.0 and two USB 2.0 ports.
- Germ-Resistant Surface - Utilizes Nano-ionic silver technology to create a germ-resistant environment on the 9H tempered glass surface.
- Wireless Connectivity - Offers optional Wi-Fi 6 and Bluetooth 5.2 for enhanced wireless screen sharing via InstaShare 2.
Ideal for: Classrooms, boardrooms, and government offices across the GCC and Africa requiring reliable, high-touch interactive displays.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- SD card slot
- N/A
- Orientation
- Landscape
Display
- Backlight
- D-LED
- Blue light filter
- Yes
- Brightness
- 450 nits
- Colour depth
- 10bit
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 65"
- Surface protection
- 9H tempered
- Viewing angle
- 178° (H) / 178° (V)
- Aspect ratio
- 16:9
- Colour gamut
- 72% NTSC
- Contrast ratio
- 1200:1
- Panel technology
- IPS
- Response time
- 8 ms
Touch
- Touch points
- up to 40
- Touch response time
- < 5 ms
- Touch technology
- High Precision IR
System
- Ambient light sensor
- Yes
- Processor
- Arm Cortex-A73 × 4 + A53 × 4
- Graphics
- Arm Mali-G52 MP8
- OPS slot
- Optional
- Operating system
- Android 13
- RAM
- 8 GB
- Storage
- 128 GB
- Operating hours
- 18 hours / 7 days
- Storage conditions
- -10°C ~ 60°C | 14°F ~ 140°F
Connectivity
- Bluetooth
- Bluetooth 5.2
- DisplayPort
- DP 1.2a × 1
- Ethernet (RJ45)
- RJ45 (1000 Mbps Port) × 1
- HDMI input
- HDMI In (HDMI 2.0) × 3
- HDMI output
- HDMI Out × 1
- NFC card reader
- Yes
- Serial port
- RS232 × 1
- Touch USB ports
- Touch-USB 3.0 × 3
- USB-C
- 1 × 3.0 (PD 65 W), 2 × 3.0
- USB ports
- USB 3.0 × 5, USB 2.0 × 2
- VGA input
- VGA × 1
- Wi-Fi
- Wi-Fi 6 (optional)
Camera & audio
- Audio in
- Audio In × 1
- Audio out
- Audio Out × 1
- Built-in camera
- Yes
- Camera
- N/A
- Speaker output
- 2 × 20 W (max)
- Speaker type
- Built-in Speakers
- Microphone
- 8-microphone array (range: up to 8 m | 26ft)
Physical & warranty
- In the box
- 1 × VGA (3 m | 9.8 ft), 1 × HDMI (3 m | 9.8 ft), 1 × USB-B for touch (3 m | 9.8 ft), 1 × USB-C (1.5 m | 4.9 ft)
- Operating humidity
- 20% ~ 80% RH non-condensing
- Operating temperature
- 0°C ~ 40°C | 32°F ~ 104°F
- Power consumption
- 106.1 W
- Standby power
- <0.5 W
- Dimensions
- 1489.3 × 905.8 × 87.1 mm (58.6 × 35.7 × 3.4 inch)
- Weight
- 37.8 kg
- Shipping dimensions
- 1640.0 × 1010.0 × 185.0 mm (64.6 × 39.8 × 7.3 inch)
- VESA mount
- VESA 600 × 400 mm ( 4 × M8 × 25L)
- Input voltage
- AC 100-240V 50/60Hz
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Is the BenQ Board Master RM6504 Google EDLA certified?
Yes, the device is Google EDLA certified, allowing direct access to Google Play apps and services without third-party modifications.
Which countries can you deliver the RM6504 to?
Smart-Boards ships to all GCC countries and African nations through established logistics partners, ensuring lowest possible cost for your region.
Do you provide on-site installation outside the UAE?
On-site installation is available within the UAE only. For other countries, the unit is delivered ready for local setup with remote guidance if needed.
What is the maximum touch point capacity?
The high-precision IR touch technology supports up to 40 simultaneous touch points with a response time of less than 5 ms.
Does it include an internal camera?
No, the RM6504 does not include an internal camera. You may connect an external USB camera for video conferencing needs.
What is the OPS slot specification?
It features one OPS slot designed for slot-in PCs, allowing you to add a Windows computer directly into the display chassis.
Can I get a demonstration before purchasing?
Yes, Smart-Boards offers live or virtual demonstrations before purchase to verify suitability for your specific regional and technical requirements.
