The Dahua LPH65-ST430 is a 65-inch interactive flat panel featuring 4K UHD resolution and Android 14. Designed for collaborative environments, it offers 40-point touch accuracy and quad-core processing. Smart-Boards supplies this unit across the GCC and Africa.
This 65-inch interactive display combines a 3840 x 2160 screen with infrared touch technology supporting up to 40 simultaneous touch points on Windows and 32 on Android. The metal-cased unit runs Android 14 on a quad-core processor with 8 GB RAM and 128 GB storage. Connectivity includes three HDMI inputs, USB-C, and dual 20 W speakers for clear audio output in meeting rooms or classrooms.
Built for durability, the panel features a 4,000:1 contrast ratio and 178-degree viewing angles to ensure visibility from multiple seats. It supports 802.11ax Wi-Fi and Bluetooth 5.4 for wireless connectivity, alongside an RS-232 port for system integration. The device operates on 100–240 V AC power and meets Energy Star standards, making it suitable for multi-site deployments across diverse regions.
Key features
- High-Definition Display - The 65-inch panel delivers 3840 x 2160 resolution with 400 nits brightness for clear visual content.
- Multi-Touch Capability - Infrared touch technology enables 40-point interaction on Windows and 32-point on Android with ±1.5 mm accuracy.
- Android 14 Operating System - Powered by Android 14 with a quad-core Cortex-A73 processor, 8 GB RAM, and 128 GB internal storage.
- Comprehensive Connectivity - Features three HDMI 2.1 inputs, USB-C, RJ-45, RS-232, and dual 20 W speakers for versatile integration.
- Energy Efficient Design - Certified Energy Star with standby power below 0.5 W and a metal casing for robust structural integrity.
Ideal for: Classrooms, corporate boardrooms, and government training centers across the GCC and Africa requiring reliable interactive displays.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- LPH65-ST430
- Product type
- Interactive Flat Panel
- Key features
- Android 14, 4K UHD, 32/40-point touch, two full-range speakers, OPS port, 802.11ax Wi-Fi, Bluetooth 5.4, Energy Star
Display
- Colour
- Black
- Backlight
- DLED
- Brightness
- 400 cd/m²
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 65"
- Viewing angle
- 178° (H) / 178° (V)
- Aspect ratio
- 16:9
- Colour gamut
- 72% NTSC
- Contrast ratio
- VA: 4,000:1; IPS: 1,200:1 (typical)
- Frequency response
- 140 Hz–20 kHz
- Response time
- 8 ms
Touch
- Touch accuracy
- ±1.5 mm
- Touch points
- 32-point Android, 40-point Windows multi-touch
- Touch response time
- ≤5 ms
- Touch technology
- Infrared
System
- Processor
- Quad-core Cortex-A73
- Graphics
- Mali G52MC1
- Operating system
- Android 14
- RAM
- 8 GB
- Storage
- 128 GB
Connectivity
- Bluetooth
- Bluetooth 5.4
- Wi-Fi
- 802.11 a/b/g/n/ac/ax
- Ports
- HDMI In × 3 (4K@60 Hz), USB 2.0 Type-A × 3, USB 3.2 Type-A × 1, USB-C × 1, USB Touch Type-B × 2, RS-232 × 1, RJ-45 × 1
Camera & audio
- Speaker output
- 2 × 20 W
- Speaker configuration
- 2 full-range speakers, 2.0 channel
Physical & warranty
- Material
- Metal casing
- Operating humidity
- 10% to 90% RH
- Operating temperature
- 0 to 40 °C
- Power consumption
- 138 W (basic), 240 W (max)
- Standby power
- ≤0.5 W
- Dimensions
- 1485.2 x 916.6 x 116.5 mm
- Weight
- 35 kg
- VESA mount
- 500 x 400 mm
- Input voltage
- 100–240 V AC, 50/60 Hz
- Certifications
- CE, EDLA, Energy Star
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Is the Dahua LPH65-ST430 suitable for large meeting rooms?
Yes. The 65-inch screen and 400-nit brightness ensure visibility in well-lit environments. The 178-degree viewing angles allow participants at the sides to see the content clearly without color distortion.
Does the panel support wireless screen mirroring?
Yes. The device includes built-in Wi-Fi 6 (802.11ax) and Bluetooth 5.4, allowing for wireless connectivity and casting from compatible devices without additional adapters.
What is the touch technology used?
The panel uses infrared touch technology. It supports up to 40 touch points on Windows and 32 on Android, with a response time of less than 5 ms for precise interaction.
Which countries can the LPH65-ST430 be delivered to?
We supply this model to all GCC countries (UAE, KSA, Qatar, Kuwait, Oman, Bahrain) and select African nations. Delivery is managed through established logistics partners to ensure secure transport.
Is installation included for orders outside the UAE?
No. On-site installation is available only within the UAE. For other regions, the unit is delivered ready for local setup, with remote guidance provided if needed during configuration.
What are the VESA mount requirements?
The panel supports a VESA mount pattern of 500 x 400 mm. The unit weighs 35 kg, so a compatible wall bracket or mobile stand rated for this weight is required.
Does the device have an OPS slot?
Yes. The product specifications confirm the inclusion of an OPS (Open Pluggable Specification) slot, allowing for the insertion of optional Windows computing modules for enhanced functionality.
Delivery across the GCC & Africa
We ship to the UAE, Saudi Arabia, Qatar, Kuwait, Bahrain, Oman and across Africa at the lowest possible cost through established logistics partners. Lead times and freight are stated clearly in your quotation.
On-site installation in the UAE
Professional installation, mounting and configuration are available within the UAE. Outside the UAE the product arrives ready for local installation, with remote setup guidance from our team.
- Export-grade packing and transit insurance
- Procurement-ready documents for tenders and projects
- Wall mount or mobile stand fitting (UAE)
- Manufacturer warranty, optional annual maintenance contract
