The Dahua LPH65-MC470-C-S3 is a 65-inch 4K UHD interactive flat panel designed for collaborative learning and meeting spaces. It features 50-point infrared touch, a 52 MP camera with face detection, and built-in Wi-Fi 6 access point capabilities for seamless connectivity.
This 65-inch interactive flat panel delivers 4K UHD resolution with 400 nits brightness and a 1,500:1 contrast ratio for clear visuals in varied lighting. The Android 16 operating system, powered by a Quad-core A53 and A72 processor, provides 8 GB RAM and 128 GB storage. The 50-point infrared touch technology supports writing and navigation with ±0.5 mm accuracy across the screen surface.
Integrated communication tools include an 8-array microphone array with 8 to 12 m pickup range and a 52 MP camera with face detection. Connectivity options feature Wi-Fi 6 access point support, Bluetooth 5.4, and extensive ports including three HDMI inputs, two USB-C ports, and dual RJ-45 jacks. The unit weighs 38 kg and supports VESA 500 x 400 mm mounting for wall or mobile bracket installation.
Key features
- 4K UHD Display - 65-inch screen with 3840 x 2160 resolution and 90% NTSC color gamut.
- 50-Point Touch - Infrared touch technology with 32,767 x 32,767 resolution and ±0.5 mm accuracy.
- Integrated Camera - 52 MP camera with face detection for video conferencing and attendance tracking.
- Audio Array - 8-array microphone system with 8 to 12 m pickup range and 2 × 20 W speakers.
- Wi-Fi 6 Access Point - Built-in Wi-Fi 6 access point supporting 2.4 GHz and 5 GHz bands for device connectivity.
Ideal for classrooms, boardrooms, and collaborative workspaces, this panel suits buyers across the GCC and Africa seeking integrated AV solutions for multi-site rollouts.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- LPH65-MC470-C-S3
- Product type
- Interactive Flat Panel
- Key features
- Android 16, 4K UHD, 50-point touch, 52 MP camera with face detection, 8-array microphone, 2 × 20 W speakers, Wi-Fi 6 access point, Bluetooth 5.4
- IP rating
- IP20
Display
- Colour
- Black on left and right, dark blue on top and bottom
- Backlight
- DLED
- Brightness
- 400 cd/m²
- Refresh rate
- 60 Hz
- Resolution
- 4K UHD
- Screen size
- 65"
- Surface protection
- 3 mm anti-dazzle tempered glass
- Viewing angle
- 178° horizontal / 178° vertical
- Aspect ratio
- 16:9
- Colour gamut
- 90% NTSC
- Contrast ratio
- 1,500:1
Touch
- Touch accuracy
- ±0.5 mm (covers 90% of the area)
- Touch points
- 50 points (Android and Windows)
- Touch resolution
- 32,767 x 32,767
- Touch technology
- Infrared
System
- Processor
- Quad-core A53 + quad-core A72
- Operating system
- Android 16
- RAM
- 8 GB
- Storage
- 128 GB
- Storage conditions
- -20 to 60 °C, 0% to 93% RH, 101 kPa
Connectivity
- Bluetooth
- Bluetooth 5.4
- Wi-Fi
- 802.11b/g/n/a/ac/ax, Wi-Fi 6 access point (2.4 GHz and 5 GHz)
- Ports
- HDMI IN × 3; HDMI OUT × 1; Type-C × 2; DP IN × 1; USB 3.0 × 4; USB 2.0 × 1; RJ-45 × 2; SD card slot (up to 512 GB); RS-232; SPDIF out; line in and line out; VGA in
Camera & audio
- Built-in camera
- Yes
- Camera
- 52 MP, face detection
- Speaker output
- 2.0 channel, 2 × 20 W
- Microphone
- 8 arrays, 8 m to 12 m pickup
Physical & warranty
- Mounting type
- Wall mount or mobile bracket
- In the box
- Smart display, 2 stylus pens, wall-mount bracket, wireless plug-in module, power cord, quick start guide, expansion tube and screw set, remote control
- Operating humidity
- 0% to 93% RH, 101 kPa
- Operating temperature
- 0 to 40 °C
- Power consumption
- 100 W (basic); 300 W (max)
- Standby power
- ≤0.5 W
- Dimensions
- 1485.4 x 942.2 x 115.7 mm
- Weight
- 38 kg
- VESA mount
- 500 x 400 mm
- Shipping weight
- 45.2 kg
- Input voltage
- 100–240 V AC, 50/60 Hz
- Certifications
- CE, CB, EDLA
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Does the Dahua LPH65-MC470-C-S3 support Windows?
Yes, the panel runs Android 16 natively but supports Windows 11 or Android via the included external module. The wireless plug-in module allows connection to external computers for expanded functionality.
Can this interactive flat panel be installed in countries outside the UAE?
On-site installation is available within the UAE only. For other GCC and African countries, the unit is delivered ready for local setup with remote guidance provided by our technical team if needed.
Which countries does Smart-Boards ship to?
Smart-Boards ships to all GCC countries including UAE, KSA, Qatar, Kuwait, Oman, and Bahrain, as well as various African nations. We use established logistics partners to ensure cost-effective delivery to your location.
What is the touch technology used?
The display uses infrared touch technology supporting up to 50 touch points simultaneously on both Android and Windows modes. It offers high precision with ±0.5 mm accuracy covering 90% of the screen area.
Does the package include a wall mount?
Yes, the box includes a wall-mount bracket along with the smart display, 2 stylus pens, wireless plug-in module, power cord, remote control, and necessary screws for secure installation.
What is the power consumption?
The unit consumes 100 W during basic operation and up to 300 W at maximum load. Standby power is less than 0.5 W, making it energy efficient for continuous use in educational or corporate environments.
Is the pricing fixed?
Pricing is by quotation only. We offer education, government, bulk, and tender options. Contact our team for a quote tailored to your country and order size, including delivery time confirmation.
