The Barco OverView MVL-6715 is a 67-inch rear-projection DLP video wall cube designed for high-impact visual presentations. Featuring a 1,200,000:1 dynamic contrast ratio and 305-nit brightness, it delivers clear imagery in control rooms and broadcast studios. Smart-Boards supplies this unit across the GCC and Africa.
This rear-projection video wall cube utilizes LED light sources with six-fold redundancy to ensure consistent output and extended operational life. The display achieves a brightness of 305 nits and a dynamic contrast ratio of 1,200,000:1, rendering deep blacks and vivid colors. Its 67-inch screen size and 1400 x 1050 resolution provide substantial visual real estate for detailed monitoring without requiring excessive wall space.
Connectivity is managed via dual-link DVI loop-through ports, allowing straightforward signal integration into existing AV infrastructures. The unit includes an Ethernet web server for remote management and supports genlock frequencies between 49–61 Hz for synchronized multi-display setups. With power consumption ranging from 150 W in Eco mode to 270 W maximum, it offers efficient operation for 24/7 deployment environments.
Key features
- High Contrast Output - Delivers a dynamic contrast ratio of 1,200,000:1 for sharp image definition and deep black levels on the 67-inch screen.
- Redundant LED Source - Equipped with an LED light source featuring 6x redundancy to maintain performance and extend lamp life up to 80,000 hours in Eco mode.
- Signal Loop-Through - Features dual-link DVI input and output ports to facilitate easy signal chaining and integration into complex video wall arrays.
- Remote Management - Includes an integrated Ethernet web server for remote monitoring, configuration, and control of the display unit via network.
- Genlock Synchronization - Supports genlock frequencies from 49–61 Hz, enabling precise synchronization for multi-panel installations requiring frame-accurate alignment.
- Energy Efficient Operation - Consumes as little as 150 W in Eco mode, reducing energy costs while maintaining 305 nits of brightness for clear visibility.
Ideal for: Control rooms, broadcast studios, and command centers requiring high-brightness rear-projection displays, suitable for buyers across the GCC and Africa.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- OverView MVL-6715
- Product type
- Rear-Projection Video Wall Cube
- Key features
- LED light source with 6x redundancy, Sense5 self-calibration, dual-link DVI loop-through, web server, genlock 49–61 Hz
- Lamp life
- 60,000 hours (typical), 80,000 hours (Eco)
Display
- Brightness
- 305 cd/m²
- Resolution
- 1400 × 1050
- Screen size
- 67"
- Colour gamut
- EBU
- Contrast ratio
- 1,200,000:1 (dynamic)
- Display type
- Rear-projection DLP
Connectivity
- Ports
- Dual-link DVI In × 1, Dual-link DVI Out × 1
- Connectivity options
- Dual-link DVI loop-through, Ethernet web server, optional WEB service API
Physical & warranty
- Power consumption
- 150 W (Eco), 200 W (typical), 270 W (maximum)
- Dimensions
- 1364 x 1023 x 942 mm (W x H x D)
- Weight
- 80.5 kg (projection module), 21 kg (pedestal)
- Warranty
- 2 years
- Colour temperature
- 6500K white point
- Input voltage
- 90–240 V AC, 50–60 Hz
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
Can this video wall be delivered to all GCC and African countries?
Yes, Smart-Boards ships the Barco OverView MVL-6715 to all GCC nations and selected African countries through established logistics partners. Delivery times vary by location and order size, and are confirmed in your quotation. We manage cross-border logistics to ensure the unit arrives securely for local setup.
Is on-site installation included for deliveries outside the UAE?
No, on-site installation is provided within the UAE only. For deliveries to other countries, the unit is shipped ready for local setup. We offer remote guidance to assist your technical team with the physical installation and initial configuration to ensure proper alignment and operation.
Does the MVL-6715 support multi-display synchronization?
Yes, the unit supports genlock at frequencies between 49–61 Hz. This allows you to synchronize multiple video wall cubes for a unified visual output, which is essential for broadcast environments and large-scale control rooms where frame-accurate alignment is required.
What is the expected lifespan of the LED light source?
The LED light source has a typical life of 60,000 hours, extending to 80,000 hours when operated in Eco mode. The system includes 6x redundancy, meaning the display continues to function even if individual LED modules require maintenance, ensuring high availability.
How is the display managed remotely?
The video wall cube includes an integrated Ethernet web server. This allows you to monitor status, adjust settings, and manage the unit remotely over a network. It supports optional WEB service API integration for custom automation workflows within your existing facility management systems.
Delivery across the GCC & Africa
We ship to the UAE, Saudi Arabia, Qatar, Kuwait, Bahrain, Oman and across Africa at the lowest possible cost through established logistics partners. Lead times and freight are stated clearly in your quotation.
On-site installation in the UAE
Professional installation, mounting and configuration are available within the UAE. Outside the UAE the product arrives ready for local installation, with remote setup guidance from our team.
- Export-grade packing and transit insurance
- Procurement-ready documents for tenders and projects
- Wall mount or mobile stand fitting (UAE)
- Manufacturer warranty, optional annual maintenance contract
Ready to equip your space?
Get a tailored quote for the GCC & Africa — pricing, availability and project support in one reply.
