The AISPEECH MC04 is a compact ceiling-mounted microphone designed for standard classrooms and small teaching environments. It features a 24-element MEMS array for clear voice capture within a 3.5-meter radius. Smart-Boards supplies this device across the GCC and Africa.
Designed for standard classrooms, the AISPEECH MC04 provides discreet audio enhancement for compact teaching spaces. Its low-profile white housing fits ceiling installations without visual clutter. The unit captures the teacher’s voice clearly using a 24-element MEMS array, ensuring natural sound reinforcement. With a recommended pickup radius of 3.5 meters, it covers typical interaction zones in smaller rooms. The device operates on PoE+ power, simplifying infrastructure by drawing energy through a single RJ-45 cable. This approach reduces the need for separate power adapters in educational settings.
For multi-site rollouts across the GCC and Africa, the MC04 supports cascade connections of up to two units. This allows for extended coverage in slightly larger compact areas while maintaining audio consistency. The microphone includes four analog inputs and two analog outputs via Phoenix connectors, facilitating integration with existing audio systems. Operating temperatures range from 0 to 40 °C, making it suitable for hot climates. Smart-Boards provides quote-only pricing, with delivery times confirmed based on country and order size. Installation is available within the UAE, while other regions receive ready-to-setup units with remote guidance.
Key features
- MEMS Array Capture - A 24-element MEMS array with 48 kHz sample rate captures voice clearly within a 3.5m recommended pickup radius.
- Compact Ceiling Mount - White housing with dimensions of 270 x 270 x 54.75 mm weighs under 2 kg for discreet ceiling installation.
- PoE+ Connectivity - Connects via a single RJ-45 port for 10/100/1000M data and power, consuming 12 W of power.
- Analog I/O Options - Provides four analog inputs and two analog outputs using Phoenix connectors for flexible system integration.
- Cascade Capability - Supports cascading up to two units to extend coverage in slightly larger compact teaching environments.
- Climate Resilience - Operates in temperatures of 0 to 40 °C with humidity levels between 20% and 95% RH.
Ideal for: Standard classrooms, compact teaching spaces, and small meeting rooms where clear teacher voice capture is required, suitable for buyers across the GCC and Africa.
Request a quote: email info@procure.ae or call +971 4 546 5041. Smart-Boards: supply and shipping across the GCC and Africa, installation in the UAE.
General
- Model
- MC04
- Product type
- Ceiling Microphone
- Key features
- 24-element MEMS array, 48 kHz sample rate, 35 dB noise suppression, 2 m recommended reinforcement radius, 3.5 m recommended pickup radius, cascade up to 2 units
- PoE
- PoE+
- Signal-to-noise ratio
- 73.9 dBA
Display
- Colour
- White
System
- Storage conditions
- -20 to +70 °C
Connectivity
- Inputs
- 4 analog
- Outputs
- 2 analog
- Ports
- RJ-45 10/100/1000M PoE × 1, Analog In × 4 (Phoenix), Analog Out × 2 (Phoenix)
Camera & audio
- Microphone type
- 24-element MEMS array
- Pickup range
- 3.5 m recommended pickup radius
Physical & warranty
- Mounting type
- Ceiling mount
- Operating humidity
- 20% to 95% RH
- Operating temperature
- 0 to 40 °C
- Power consumption
- 12 W
- Dimensions
- 270 x 270 x 54.75 mm
- Weight
- < 2 kg
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
What is the recommended pickup radius of the MC04?
Yes, the recommended pickup radius is 3.5 meters. This range ensures clear voice capture for the teacher in standard classrooms. The device covers the immediate teaching area effectively without requiring excessive amplification.
Can multiple MC04 units be connected together?
Yes, the MC04 supports cascading up to two units. This feature allows you to extend the audio coverage area slightly beyond a single unit's range. It is useful for slightly larger compact spaces that need consistent audio capture.
Which countries in the GCC and Africa receive delivery?
Yes, Smart-Boards ships to all GCC countries including UAE, KSA, Qatar, Kuwait, Oman, and Bahrain, as well as African nations. Delivery times depend on the country and order size, confirmed in your quotation. Logistics partners ensure cost-effective transport.
Is on-site installation available outside the UAE?
No, on-site installation is only available within the UAE. For other countries, units are delivered ready for local setup. Smart-Boards provides remote guidance to assist local technicians with the installation process effectively.
How is the MC04 powered?
Yes, the MC04 uses PoE+ (Power over Ethernet). It connects via a single RJ-45 port that provides both data and 12 W of power. This simplifies wiring by eliminating the need for a separate power adapter in the classroom.
What analog connections does the MC04 have?
Yes, the MC04 includes four analog inputs and two analog outputs. These connections use Phoenix connectors for secure attachment. This allows easy integration with existing audio mixers, amplifiers, or sound reinforcement systems in educational environments.
What is the operating temperature range for this microphone?
The MC04 operates in temperatures from 0 to 40 °C. It stores safely between -20 and +70 °C. This range suits typical indoor classroom conditions in the GCC and Africa. Humidity tolerance is 20% to 95% RH during operation.
