VSYS VS01A-46T Heavy-Duty Tilting Wall Mount for 37"–86" Displays, 80 kg. A bracket for the screens that end up higher than eye level.
Ceiling-height signage in a bank branch, a menu board above a counter, a departures screen in a terminal, a classroom panel that has to clear the whiteboard - all of these sit above the people watching them, and a flat-mounted screen in that position reflects the ceiling lights straight back. The VSYS VS01A-46T solves it with a toolless tilt that angles a 37" to 86" display downward by up to 10 degrees. Smart-Boards supplies it across the GCC and Africa alongside our interactive panel and commercial display range, with quotations and low-cost delivery to your country.
The tilt is set by hand after the screen is hanging, so the angle is judged from where people will actually be standing rather than guessed from a drawing. Underneath that, the engineering is the same heavy-duty platform as the fixed model: 1.8 mm cold-rolled steel in the wall plate and both arms, strength tested to four times the rating, 80 kg working load. The tilt mechanism needs room to swing, so the panel sits 60 mm off the wall instead of 30 mm. Spring locks and pull cords handle removal for cable access.
Key features
- Toolless tilt of plus 10 to minus 10 degrees, adjusted by hand with the display already mounted - no ladder trip back for a spanner
- 80 kg working load from 1.8 mm cold-rolled steel, strength tested to four times the rated figure
- 37" to 86" range covers classroom, meeting room and signage panels from a single part number
- Downward angle kills the ceiling-light reflection that ruins a flat-mounted screen placed above head height
- VESA from 50x50 mm to 600x400 mm, maximum hole spread 645x402 mm, fitting almost any display in the class
- 60 mm wall clearance gives the tilt mechanism its travel while still reading as a wall-flush installation
- Quick-release spring locks with pull cords, so one person can lift the panel off the plate for rear cable work
- Open-architecture plate keeps the socket outlet, cable run and ventilation path clear behind the screen
- Fixes to stud centres of 406, 450 or 600 mm, or to block and concrete with suitable anchors
- Powder-coated black steel finish, supplied with a hook-on spirit level for accurate levelling
| Brand | VSYS |
|---|---|
| Cable management | Open architecture wall plate, clear access to outlets and cabling |
| Colour | Black |
| Display compatibility | 37 inch to 86 inch flat and curved panels |
| In the box | Wall plate, bracket arms, mounting hardware kit for solid wall or dual stud, hook-on spirit level, installation instructions |
| Material | 1.8 mm cold-rolled steel, powder coated |
| Max load | 80 kg (176 lbs) |
| Mounting type | Wall mount, tilting, single screen |
| Quick release | Spring locks with pull-cord release |
|---|---|
| Stud spacing | 406 mm, 450 mm or 600 mm centres, or solid wall |
| Testing | Strength tested to 4x the rated load |
| Tilt range | Plus 10 to minus 10 degrees, toolless adjustment |
| Vesa pattern | 50x50 mm to 600x400 mm, maximum hole spread 645x402 mm |
| Wall distance | 60 mm (2.4 in) |
| Model | VS01A-46T |
How do I get a price for this product?
Do you deliver across the GCC and Africa?
Do you offer installation and setup?
Is there a warranty?
Can I order in bulk for schools or offices?
1. What is the VSYS VS01A-46T?
It is a heavy-duty tilting wall mount for a single 37" to 86" display weighing up to 80 kg. The defining feature is a toolless tilt of plus 10 to minus 10 degrees, which lets a screen mounted above eye level be angled down towards the people looking at it.
2. Is it compatible with my display?
Yes - if the screen is 37" to 86", weighs 80 kg or less and has a VESA pattern between 50x50 mm and 600x400 mm, it will fit. Tell us your display model when you request a quote and we will confirm the exact fit.
3. How much does it tilt, and do I need tools?
Ten degrees down and ten degrees up, set by hand. No tools and no need to take the display off the wall. That matters most on the day of commissioning, when the angle usually needs one or two corrections once the room is furnished and the lights are on.
4. Should I choose this or the fixed VS01A-46F?
If the screen sits at seated or standing eye level, the fixed VS01A-46F is slimmer at 30 mm and does the job. Choose the VS01A-46T when the panel goes above head height, or where overhead lighting reflects off the glass. The tilt version sits 60 mm off the wall to give the mechanism room.
5. Does the tilt angle drift once it is set?
No. The mechanism holds its position under the full rated load, and the assembly is strength tested to four times its 80 kg rating using 1.8 mm cold-rolled steel throughout. Setting the angle is deliberate, not something a knock will change.
6. Do you ship the VSYS VS01A-46T across the GCC and Africa?
Yes. Smart-Boards ships to every GCC and African country at the lowest possible cost through established logistics partners. On-site installation is available within the UAE; elsewhere the product arrives ready for local setup.
7. How do I get a price for the VSYS VS01A-46T?
Pricing is on request. Send a quote request from the product page or email info@procure.ae and we return a procurement-ready quotation, including education and bulk pricing.
8. Is installation included?
Within the UAE, yes - our team can install and set up the unit. Outside the UAE we ship it ready for local installation and provide setup guidance on request. A hook-on spirit level is supplied so the wall plate is levelled before the display goes on.
9. Can I get behind the screen after installation?
Yes. Two pull cords release the spring locks and the display lifts off the wall plate, which one person can manage on most panels in the range. The open plate design also leaves the socket outlet and cable run accessible without removing the screen at all.
10. Can you supply large quantities for a rollout?
Yes - Smart-Boards handles multi-unit rollouts across the GCC and Africa, with volume pricing and procurement-ready documentation for tenders and education projects.
